Table 23. S9V2D120U5PSBC/D / S9V2D120D5PSBC/D Cooling Airflow
S9V2D120U5PSBC/D / S9V2D120D5PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static
Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1336 1346 1354 1360 1363
Watts 163 221 281 341 402
Cooling 420
CFM/Ton
CFM 1248 1258 1265 1271 1274
Watts 137 191 247 304 361
Cooling 400
CFM/Ton
CFM 1189 1199 1206 1211 1214
Watts 121 173 227 281 336
Cooling 370
CFM/Ton
CFM 1102 1110 1116 1121 1123
Watts 100 148 198 249 301
Cooling 350
CFM/Ton
CFM 1043 1051 1057 1060 1062
Watts 87 133 181 230 279
Cooling 330
CFM/Ton
CFM 985 991 996 999 1000
Watts 76 119 165 211 259
Cooling 310
CFM/Ton
CFM 927 932 936 937 938
Watts 65 107 150 195 241
Cooling 290
CFM/Ton
CFM 869 872 874 875 875
Watts 56 95 136 179 223
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1559 1567 1574 1579 1583
Watts 244 312 381 450 519
Cooling 420
CFM/Ton
CFM 1455 1464 1472 1477 1481
Watts 204 267 331 396 462
Cooling 400
CFM/Ton
CFM 1386 1395 1403 1409 1413
Watts 179 240 301 363 426
Cooling 370
CFM/Ton
CFM 1282 1292 1300 1305 1309
Watts 147 203 260 318 376
Cooling 350
CFM/Ton
CFM 1214 1223 1231 1236 1239
Watts 127 181 235 290 346
Cooling 330
CFM/Ton
CFM 1145 1154 1161 1166 1169
Watts 110 160 212 265 318
Cooling 310
CFM/Ton
CFM 1077 1085 1092 1096 1098
Watts 94 142 191 241 292
Cooling 290
CFM/Ton
CFM 1009 1016 1021 1025 1026
Watts 80 125 171 219 267
Cooling
4.0 Ton
Cooling 450
CFM/Ton
CFM 1783 1789 1793 1796 1798
Watts 350 427 505 584 663
Cooling 420
CFM/Ton
CFM 1663 1671 1677 1681 1683
Watts 290 362 436 509 583
Cooling 400
CFM/Ton
CFM 1584 1592 1599 1603 1607
Watts 255 324 393 464 534
Cooling 370
CFM/Ton
CFM 1465 1474 1481 1487 1491
Watts 207 271 336 401 467
Cooling 350
CFM/Ton
CFM 1386 1395 1403 1409 1413
Watts 179 240 301 363 426
Cooling 330
CFM/Ton
CFM 1307 1317 1324 1330 1334
Watts 154 211 269 328 388
Cooling 310
CFM/Ton
CFM 1228 1238 1246 1251 1254
Watts 131 185 240 296 352
Cooling 290
CFM/Ton
CFM 1150 1159 1166 1171 1174
Watts 111 162 214 266 320
Cooling
4.5 Ton
Cooling 450
CFM/Ton
CFM 2010 2011 2012 2011 2010
Watts 482 569 657 745 834
Cooling 420
CFM/Ton
CFM 1874 1878 1881 1882 1883
Watts 399 480 562 645 727
Cooling 400
CFM/Ton
CFM 1783 1789 1793 1796 1798
Watts 350 427 505 584 663
Cooling 370
CFM/Ton
CFM 1648 1656 1662 1666 1669
Watts 283 355 427 500 574
Cooling 350
CFM/Ton
CFM 1559 1567 1574 1579 1583
Watts 244 312 381 450 519
Cooling 330
CFM/Ton
CFM 1470 1479 1486 1492 1495
Watts 209 273 338 404 469
Cooling 310
CFM/Ton
CFM 1381 1390 1398 1404 1408
Watts 178 238 299 361 423
Cooling 290
CFM/Ton
CFM 1292 1302 1310 1315 1319
Watts 149 206 264 322 381
