Trane SCIH Installation, Operation And Maintenance Instructions

10 SXIH-SVX01B-EN
dimensions
and weights
Installation
SCIH Accessories
A
C
B
Low Ambient Damper
SCIH Low Ambient Damper Dimensions & Weight, in-lbs.
Unit
Size A B C Weight
5 & 7.5 ton 19
1
/
8
7
7
/
8
11 20
10 & 15 ton 52
3
/
4
7
7
/
8
11 40
A
C
B
SCIH Plenum Dimensions & Weight, in-lbs.
Unit Size A B C Grill Size (W x H) Weight
5 ton 42
3
/
4
16
1
/
4
31
1
/
2
38
3
/
4
x 12
3
/
4
76
7.5 ton 56
3
/
4
16
1
/
4
31
1
/
2
52
3
/
4
x 12
3
/
4
95
10 & 15 ton 85
7
/
8
16
1
/
4
31
1
/
2
81
7
/
8
x 12
3
/
4
141
Note: Low ambient damper is field-installed.
Plenum
