22 SXIH-SVX01B-EN
Maintenance
general
information
Table M-GI-1. Integral Air-Cooled General Data
Nominal Tons 5 7. 5 10 15
ARI capacity - btu/h 60,600 91,000 121,900 177,200
(S)EER 10.47
1
10.36 10.38 9.76
R22 charge/circuit (lbs.) 9.2 14.3 9.3 11.7
Shipping weight – lbs. 908 1087 1495 1897
Operating weight – lbs. 848 1027 1445 1767
Compressor, qty - hp 1 1 2 2
Circuits 1 1 2 2
Condenser
Face area, sq/ ft. 6.74 10.75 16.55 16.55
Rows / fpf 4 / 180 4 / 168 3 / 180 4 / 180
Fans, qty. 1 1 2 2
Fan size, in. 15x15 15x15 15x15 15x15
Motor hp 1.5 2.0 2.0 5.0
Evaporator
Face area, sq. ft 5.99 8.32 12.82 12.82
Rows / fpf 4 / 144 4 / 144 4 / 144 4 / 144
Filter qty. - size, in. 2- 23.7x18 2 - 23.7x25 3 - 23.7x25.6 3 - 23.7x25.6
Fans qty. - size, in 1- 12x12 1 - 12x12 2 - 12x12 2 - 12x12
Motor hp 1.0 1.5 2.0 3.0
Min. airflow 1800 2700 3600 5400
Max. airflow 2200 3300 4400 6600
Notes: 1. Net cooling capacity is rated at 95°F ambient, 80°F entering dry bulb and 67°F entering wet bulb at scfm air
condition. 2. EER is rated at ARI conditions.
Footnote 1. SEER applies to 5-ton unit--ARI 210-240 Certified.
