Trane SCIH Installation, Operation And Maintenance Instructions

4 SXIH-SVX01B-EN
Installation
general
information
Integral Air-Cooled Model Number Description
Following is a complete description of the integral air-cooled unit model number. Each digit in the model number has a corresponding
code that identifies specific unit options.
S C I H 0 7 5 3 1 A 0 1 0 1 0 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Digit 1 - Unit Model
S = self contained
Digit 2 - Unit Type
C = commercial
Digit 3 - Condenser Medium
I = integral air-cooled
Digit 4 - Development Sequence
H = development series
Digit 5, 6, 7- Unit Nominal Capacity
050 = 5 tons
075 = 7.5 tons
100 = 10 tons
150 = 15 tons
Digit 8 - Unit Voltage
3 = 208 - 230 volt/60 hz/3 ph
4 = 460 volt/60 hz/3 ph
5 = 575 volt/60 hz/3 ph
Digit 9 - Air Flow Configuration
1 = horizontal discharge / rear return
2 = vertical discharge / front return
3 = vertical discharge / rear return
Digit 10, 11 - Design Sequence
A0 = design sequence
Digit 12 - Air Filter Type
1 = one-inch fiberglass throwaway
Digit 13 - Control
0 = control interface
Digit 14 - Unit Finish
1 = painted
2 = coated finish only
Digit 15 - Coil Finish
0 = none
C = condenser coated
E = evaporator coated
H = condenser + evaporator coated
Digit 16 - Agency Listing
A = C ETL listing
