SXIH-SVX01B-EN 5
Installation
general
information
Accessory Model Number Description
Following is a complete description of the integral air-cooled accessory model number. Each digit in the model number has a
corresponding code that identifies specific unit options.
P V I H A A 1 1 1 A0 A 0 1 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Digit 1 - Parts/Accessories
P = parts/accessories
Digit 2 - Unit Model
V = vertical self contained
Digit 3 - Condenser Medium
I = integral air-cooled
Digit 4 - Development Sequence
H = development sequence
Digit 5 - Thermostat
0 = none
A = 10/15 ton t-stat 2C w/auto base
D = 10/15 ton prg. t-stat 2H2C w/2H2C
base
E = 10/14 ton t-stat 2H2C w/auto base
F = 10/15 ton t-stat 2H2C w/auto/mnl
base
G = 10/15 ton t-stat 2H2C w/mnl base
H = 5/7.5 tonprg t-stat 2H2C w/mnl base
J = 5/7.5 ton t-stat 1H1C base
K = 5/7.5 ton t-stat 1H1C w/auto/mnl
base
L = 5/7.5 ton t-stat 1H1C w/mnl base
Digit 6 - Remote Wall Sensor
0 = none
A = remote wall sensor
Digit 7 - Heat Coil
0 = none
1 = 5-ton hot water coil
2 = 7.5-ton hot water coil
3 = 10/15-ton hot water coil
4 = 5-ton steam coil
5 = 7.5-ton steam coil
6 = 10/15-ton steam coil
Digit 8 - Discharge Plenum
0 = none
1 = 5-ton plenum
2 = 7.5-ton plenum
3 = 10-ton plenum
4 = 15-ton plenum
Digit 9 - Low Ambient Damper
0 = none
1 = 5/7.5-ton low ambient damper
2 = 10/15-ton low ambient damper
Digit 10 - Design Sequence
** = factory assigned
Digit 11 - Oversize Motor Condenser
0 = none
A = 5-ton, 208V condenser, OS motor kit
B = 7.5-ton, 208V condenser, OS motor
C = 10-ton, 208V condenser, OS motor
D = 15-ton, 208V condenser, OS motor
E = 5-ton, 460V condenser, OS motor
F = 7.5-ton, 460V condenser, OS motor
G = 10-ton, 460V condenser, OS motor
H = 15-ton, 460V condenser, OS motor
J = 5-ton, 575V condenser, OS motor
K = 7.5-ton, 575V condenser, OS motor
L = 10-ton, 575V condenser, OS motor
M = 15-ton, 575V condenser, OS motor
Digit 12 - Oversize Motor Evaporator
0 = none
A = 5-ton, 208V evaporator, OS motor
B = 7.5-ton, 208V evaporator, OS motor
C = 10-ton, 208V evaporator, OS motor
D = 15-ton, 208V evaporator, OS motor
E = 5-ton, 460V evaporator, OS motor
F = 7.5-ton, 460V evaporator, OS motor
G = 10-ton, 460V evaporator, OS motor
H = 15-ton, 460V evaporator, OS motor
J = 5-ton, 575V evaporator, OS motor
K = 7.5-ton, 575V evaporator, OS motor
L = 10-ton, 575V evaporator, OS motor
M = 15-ton, 575V evaporator, OS motor
Digit 13 - Filter
0 = none
1 = 5-ton 1” fiberglass TA, 6PC
2 = 5-ton 2” fiberglass TA, 6PC
3 = 5-ton 2” mesh filter washable, 6PC
4 = 7.5-ton 1” fiberglass TA, 6PC
5 = 7.5-ton 2” fiberglass TA, 6PC
6 = 7.5-ton 2” mesh filter washable,
6PC
7 = 10/15-ton 1” fiberglass TA, 6PC
8 = 10/15-ton 2” fiberglass TA, 6PC
9 = 10/15-ton 2” mesh filter washable,
6PC
Digit 14 - Filter Rack Kit
0 = none
A = 5-ton filter rack kit
B = 7.5-ton filter rack kit
C = 10-ton filter rack kit
D = 15-ton filter rack kit
