26 69-1791
22-5207-01
4. Align the screw blocks with the pins on the back of the comfort control.
5. Push the comfort control straight onto the wallplate until it snaps into place.
M22652
PINS ON
BACK OF
COMFORT
CONTROL
WALLPLATE
TERMINAL
SCREW
BLOCK
