1.4.1 Frame Size Denitions

Model HP @200–240 V AC kW @200–240 V AC Frame Size IP Rating Repairable Yes/No

PK25 0.33 0.25 H1 IP20 No

PK37 0.5 0.37 H1 IP20 No

PK75 1.0 0.75 H1 IP20 No

P1K5 2.0 1.5 TR150: H1

TR170: H2

IP20 No

P2K2 3.0 2.2 H2 IP20 No

P3K7 5.0 3.7 H3 IP20 No

P5K5 7.5 5.5 H4 IP20 No

P7K5 10.0 7.5 H4 IP20 No

P11K 15.0 11.0 H5 IP20 No

P15K 20.0 15.0 H6 IP20 Yes

P18K 25.0 18.5 H6 IP20 Yes

P22K 30.0 22.0 H7 IP20 Yes

P30K 40.0 30.0 H7 IP20 Yes

P37K 50.0 37.0 H8 IP20 Yes

P45K 60.0 45.0 H8 IP20 Yes

Table 1.2 TR150 and TR170 Frequency Converters 200–240 V AC

Introduction TR150 and TR170 Service Manual

1 1
