12 BAS-SVN040B-EN
Installation
Location and Mounting Guidelines
Location
The location should meet the following operating environment requirements and clearances:
Table 4. Operating environment specifications
Temperature: From 32°F to 122°F (0°C to 50°C)
Humidity: 5–95% non-condensing
Power Requirements: 120 Vac: 9A maximum, 1 phase, 60 Hz
Weight: Mounting surface must be able to support 60 lb. (28 kg)
Dimensions: 16 ½ in. × 14 ¾ in. × 5 ½ in. (418 mm × 373 mm × 140 mm)
Installation: U.L. 840: Category 3
Pollution: U.L. 840: Degree 2
Important: The Tracer Concierge Panel enclosure must be installed indoors.
Trane recommends locating the enclosure:
• Where service personnel have easy
access.
• In areas that restrict public access to mi
nimiz
e tampering or vandalism.
Mounting Instructions
Note: The internal enclosure panel comes with four (4) mounting holes (refer to the locations in
Figure 5, p. 10).
1. Using the enclosure as a template, mark th
e location of the four (4) mounting holes on the
mounting surface to accommodate the supplied #10 screws and/or #10 wall anchors.
2. Set aside the enclosure and drill the marked lo
cation holes for the screws.
Note: Use wall
anchors if the mounting surface is dry wall or masonry.
3. Secure the enclosure to the mounting surface with the enclosed #10
screw
s and #10 wall anchors.
4. Remove the tie wraps that secure the modules t
o the DIN ra
il during shipping.
Wiring High Voltage AC Power
Read all WARNINGS, CAUTIONS, and NOTICES prior to wiring high-voltage AC power.
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could result in death or serious injury.Disconnect
all electric power, including remote disconnects before servicing. Follow proper lockout/tagout
procedures to ensure the power can not be inadvertently energized. Verify that no power is
present with a voltmeter.
WARNING
Proper Field Wiring and Grounding Required!
Failure to follow code could result in death or serious injury. All field wiring MUST be
performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE
and ELECTROCUTION hazards. To avoid these hazards, you MUST follow requirements for field
wiring installation and grounding as described in NEC and your local/state/national electrical
codes.
