Chapter 6 UCMs supported by Tracer Summit systems
78 BMTX-SVN01C-EN
tion link wire to the TUC at the ICS terminal. Refer to the TUC installa-
tion literature (EMTX-IOP-1) for connection points.
Device addressing
Each UCM must have a unique address on each link. On the TUC, the
address is set with the SW1 address DIP switches, followed by a momen-
tary short between J11 and J12. For TUC DIP switch settings, refer to
Table 20.
Table 20. TUC address settings
UCM
address
TUC DIP switch settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
33 OFF OFF on OFF OFF OFF OFF on
34 OFF OFF on OFF OFF OFF on OFF
35 OFF OFF on OFF OFF OFF on on
36 OFF OFF on OFF OFF on OFF OFF
37 OFF OFF on OFF OFF on OFF on
38 OFF OFF on OFF OFF on on OFF
39 OFF OFF on OFF OFF on on on
40 OFF OFF on OFF on OFF OFF OFF
41 OFF OFF on OFF on OFF OFF on
42 OFF OFF on OFF on OFF on OFF
43 OFF OFF on OFF on OFF on on
44 OFF OFF on OFF on on OFF OFF
45 OFF OFF on OFF on on OFF on
46 OFF OFF on OFF on on on OFF
47 OFFOFFonOFFonononon
48 OFF OFF on on OFF OFF OFF OFF
49 OFF OFF on on OFF OFF OFF on
50 OFF OFF on on OFF OFF on OFF
51 OFF OFF on on OFF OFF on on
52 OFF OFF on on OFF on OFF OFF
53 OFF OFF on on OFF on OFF on
54 OFF OFF on on OFF on on OFF
55 OFF OFF on on OFF on on on
56 OFF OFF on on on OFF OFF OFF
57 OFF OFF on on on OFF OFF on
58 OFF OFF on on on OFF on OFF
59 OFF OFF on on on OFF on on
60 OFF OFF on on on on OFF OFF
61 OFF OFF on on on on OFF on
