Trane Tracer SC User Manual

14 BAS-SVU025A-EN
Navigating the User Interface
Using the Actions Button
The actions button is available onTracer SC pages in which certain actions can be
taken on selected items.
To delete a report (example):
1. Select a report from the Reports page.
2. Click the actions button and then select delete saved report.
Figure 2. Using the actions button
Actions button
Selected item

Trane Tracer SC Specifications

General

User Interface	Web-based interface
Controller Type	Building Automation System Controller
Communication Protocols	BACnet, Modbus, LonTalk
Power Supply	24 VAC, 50/60 Hz
Operating Temperature Range	0°C to 50°C
Humidity Range	10% to 90% RH, non-condensing
Memory	Flash memory for program and data storage
Mounting	DIN rail or wall mount
Weight	3.5 lbs
