Trane Tracer SC User Manual

4 BAS-SVU025A-EN
Creating a Triggered Data Log .................................. 23
Spaces ..........................................................25
Space Status .................................................. 26
Equipment ......................................................27
Equipment Status .............................................. 28
Schedules .......................................................29
Optimal Start/Stop ............................................. 29
Creating a Schedule ............................................ 30
Exceptions and Calendars ....................................... 30
Points ..........................................................32
Point Types ................................................... 32
Point Overrides ..................................................34
Overriding a Point .............................................. 34
Using the Override Dialog Box ................................... 35
Systems ........................................................36
Area Application ............................................... 36
Variable Air Systems (VAS) Application ............................ 36
Chiller Plant Control (CPC) Application ............................. 36
Viewing System Status .......................................... 37
Tools ...........................................................38
Backup and Restore ............................................ 38
Custom Graphics ............................................... 39
Global Referencers ............................................. 39
Programs ..................................................... 39
System Logs .................................................. 39
Tracer ES IP Address ............................................ 39
Unit Controllers ..................................................40
Trane Unit Controllers Supported by the Tracer SC .................. 40
Non-Trane Unit Controllers Supported by Tracer SC ................. 40
LEDs and the 7-Segment Display ....................................41
Powering Up/Powering Down the Tracer SC ........................ 41
The LEDs and the 7-Segment Display .............................. 41
Interpreting the LEDs ......................................... 42
Interpreting the 7-Segment Display .............................. 43
Troubleshooting ..................................................44

Trane Tracer SC Specifications

General

User Interface	Web-based interface
Controller Type	Building Automation System Controller
Communication Protocols	BACnet, Modbus, LonTalk
Power Supply	24 VAC, 50/60 Hz
Operating Temperature Range	0°C to 50°C
Humidity Range	10% to 90% RH, non-condensing
Memory	Flash memory for program and data storage
Mounting	DIN rail or wall mount
Weight	3.5 lbs
