Installing the Tracer™ TD-5 Display
This section describes installation procedures when
mounting the Tracer™ TD-5 display near the RTRM
module or remotely mounted up to 328 ft (100 m) by using
a field-su
pplied 75 mm VESA mounting bracket. Read and
observe all warning and caution statements before you
begin the installation procedure.
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury
. Disconnect all electric
power, including remote disconnects before servicing.
Follow proper lockout/tagout procedures to ensure the
power can not be inadvertently energized.
Packaged Contents
• One (1) Tracer™ TD-5 display with permanently
attached 2.6 ft (0.8 m) power cable with male connector
• Four (4) M-4 screws
• Four (4) spacer washers
Additional Mounting Parts
• TD-5 Display Low Profile Mounting Bracket (VESA
75mm) (PN: X05010511010)
Installing the TD-5 Display onto a
VESA Mounting Bracket
The Tracer™ TD-5 can be mounted near the RTRM module
in the control panel, or remotely mounted up to 328 ft
(100 m) by using a field-suppled 75 mm VESA mount.
Remote mounting requires the follo
wing additional field-
su
pplied components:
• A power source that will supply 24 VAC to the d
isplay
• Power cables
Many commercial 75mm VESA mounting brackets are
ava
ilable
, which range from a simple wall mount to tilt-
and-swivel mounts such as the one shown in Figure 2,
p. 10, or the TD-5 Display Low Profile Mounting Bracket
(VESA 75mm) (PN: X050105110
10).
To install onto a VESA mounting bracket:
1. Disconnect power at the circuit breaker and perform
l
ockout/
tagout procedures.
2. Mount the VESA mounting bracket according to
manufacturer’s instructions.
3.
Position the TD-5 display
1onto the VESA mounting
bracket 2 and align the four mounting holes with the
bracket while inserting and hand-tightening the four
M-4 screws. (Some brands of VESA mounting brackets
may require the use of the four spacer washers to allow
the M-4 screws to tighten properly.)
4. Securely tighten the M-4 screws usin
g a Phillips
screwdriver.
