Trane TSC060 User Manual

T_C-IOM-2A10
Figure 2
Unit Dimensional Data
TSC060AD
Unit Dimensions
4 1/4"
108 MM
23 9/16"
598 MM
69 7/8"
1775 MM
42 1/4"
1073 MM
9 5/8"
244 MM
5 5/8"
143 MM
5 9/16"
141 MM
7 5/8"
194 MM
44 1/4"
1124 MM
36 1/4"
921 MM

Trane TSC060 Specifications

General

Brand	Trane
Model	TSC060
Category	Chiller
Language	English
