TWE5-PRC001-EN-10-15-99 11
TWJ030CA WITH TWE040CA4-B AT 1868 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 9.0 7.4 7.9 8.5 9.1* 9.3* 2.7
29.4 17.2 9.7 6.2 6.8 7.4 8.0 8.6 2.8
19.4 10.3 5.0 5.5 6.1 6.7 7.3 2.8
21.7 11.0 3.7 4.2 4.8 5.4 6.0 2.9
15.0 8.8 7.3 7.9 8.5 8.9* 9.1* 2.8
32.2 17.2 9.5 6.2 6.7 7.3 7.9 8.5 2.9
19.4 10.1 4.9 5.4 6.0 6.6 7.2 3.0
21.7 10.8 3.6 4.2 4.7 5.3 5.9 3.1
15.0 8.6 7.2 7.8 8.4 8.8* 9.0* 2.9
35.0 17.2 9.3 6.1 6.7 7.2 7.8 8.4 3.0
19.4 9.9 4.8 5.4 6.0 6.5 7.1 3.1
21.7 10.6 3.5 4.1 4.7 5.2 5.8 3.2
15.0 8.4 7.1 7.7 8.3 8.6* 8.8* 3.0
37.8 17.2 9.1 6.0 6.6 7.1 7.7 8.3 3.1
19.4 9.7 4.7 5.3 5.9 6.4 7.0 3.2
21.7 10.3 3.4 4.0 4.6 5.2 5.7 3.3
15.0 8.2 7.0 7.6 8.2 8.4* 8.6* 3.2
40.6 17.2 8.8 5.9 6.4 7.0 7.6 8.2 3.3
19.4 9.4 4.6 5.2 5.8 6.4 6.9 3.4
21.7 10.0 3.3 3.9 4.5 5.1 5.7 3.5
15.0 7.8 6.8 7.4 7.9* 8.0* 8.2* 3.5
46.1 17.2 8.3 5.7 6.3 6.9 7.4 8.0 3.5
19.4 8.9 4.4 5.0 5.6 6.2 6.7 3.6
21.7 9.5 3.1 3.7 4.3 4.9 5.4 3.7
Performance
Data Cooling Metric Units
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1656 2165
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.07
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 9.99 KW
AIRFLOW = 1910 CMH
COMPRESSOR POWER = 3104 WATTS
I.D. FAN POWER = 300 WATTS
O.D. FAN POWER = 195 WATTS
E.E.R. = 9.05 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 22 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
TWJ036CA WITH TWE030CA4 AT 1868 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 9.9 7.6 8.1 8.7 9.3 9.8 2.5
29.4 17.2 10.8 6.6 7.1 7.6 8.2 8.8 2.6
19.4 11.6 5.4 5.9 6.5 7.0 7.6 2.7
21.7 12.5 4.2 4.7 5.3 5.8 6.4 2.8
15.0 9.8 7.5 8.1 8.6 9.2 9.7 2.7
32.2 17.2 10.6 6.5 7.0 7.6 8.1 8.7 2.7
19.4 11.4 5.3 5.9 6.4 7.0 7.5 2.8
21.7 12.2 4.1 4.7 5.2 5.8 6.3 2.9
15.0 9.6 7.4 8.0 8.6 9.1 9.6* 2.8
35.0 17.2 10.4 6.4 7.0 7.5 8.1 8.6 2.9
19.4 11.2 5.2 5.8 6.3 6.9 7.4 3.0
21.7 12.1 4.0 4.6 5.1 5.7 6.2 3.0
15.0 9.4 7.4 7.9 8.5 9.0 9.5* 2.9
37.8 17.2 10.2 6.3 6.9 7.4 8.0 8.5 3.0
19.4 11.0 5.2 5.7 6.2 6.8 7.4 3.1
21.7 11.8 4.0 4.5 5.0 5.6 6.2 3.2
15.0 9.2 7.3 7.8 8.4 8.9 9.3* 3.1
40.6 17.2 9.9 6.2 6.8 7.3 7.9 8.4 3.1
19.4 10.7 5.0 5.6 6.2 6.7 7.2 3.2
21.7 11.5 3.8 4.4 5.0 5.5 6.0 3.3
15.0 8.7 7.1 7.6 8.2 8.7 9.0* 3.3
46.1 17.2 9.4 6.0 6.6 7.1 7.7 8.2 3.4
19.4 10.2 4.8 5.4 5.9 6.5 7.0 3.5
21.7 11.0 3.7 4.2 4.7 5.3 5.8 3.6
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1656 2165
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 11.28 KW
AIRFLOW = 1910 CMH
COMPRESSOR POWER = 2957 WATTS
I.D. FAN POWER = 540 WATTS
O.D. FAN POWER = 235 WATTS
E.E.R. = 9.65 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 22 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
TWJ036CA WITH TWE040CA4-B AT 2378 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 10.9 9.0 9.7 10.4 11.0* 11.3* 2.6
29.4 17.2 11.7 7.6 8.3 9.0 9.7 10.4 2.7
19.4 12.6 6.0 6.7 7.4 8.2 8.9 2.8
21.7 13.5 4.5 5.2 5.9 6.6 7.3 2.9
15.0 10.7 8.9 9.6 10.3 10.8* 11.1* 2.8
32.2 17.2 11.5 7.5 8.2 8.9 9.6 10.3 2.8
19.4 12.4 5.9 6.7 7.4 8.1 8.8 2.9
21.7 13.3 4.4 5.1 5.8 6.5 7.2 3.0
15.0 10.5 8.8 9.5 10.2 10.7* 10.9* 2.9
35.0 17.2 11.3 7.4 8.1 8.8 9.5 10.3 3.0
19.4 12.2 5.9 6.6 7.3 8.0 8.7 3.1
21.7 13.0 4.3 5.0 5.7 6.4 7.1 3.2
15.0 10.2 8.7 9.4 10.1 10.5* 10.7* 3.0
37.8 17.2 11.0 7.3 8.0 8.7 9.4 10.1 3.1
19.4 11.8 5.7 6.4 7.1 7.9 8.6 3.2
21.7 12.7 4.2 4.9 5.6 6.3 7.0 3.3
15.0 10.0 8.6 9.3 10.0* 10.2* 10.5* 3.2
40.6 17.2 10.7 7.1 7.9 8.6 9.3 10.0 3.3
19.4 11.5 5.6 6.3 7.0 7.8 8.5 3.4
21.7 12.3 4.0 4.7 5.5 6.2 6.9 3.5
15.0 9.4 8.3 9.0 9.6* 9.8* 10.0* 3.5
46.1 17.2 10.1 6.9 7.6 8.4 9.1 9.8 3.6
19.4 10.9 5.4 6.1 6.8 7.5 8.2 3.6
21.7 11.7 3.8 4.5 5.2 5.9 6.7 3.7
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1995 2590
TOTAL CAP. X0.97 X1.01
SENS. CAP. X0.92 X1.04
COMPR. KW X0.98 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 12.10 KW
AIRFLOW = 2293 CMH
COMPRESSOR POWER = 3066 WATTS
I.D. FAN POWER = 360 WATTS
O.D. FAN POWER = 235 WATTS
E.E.R. = 10.80 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 22 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
