12 TWE5-PRC001-EN-10-15-99
Performance
Data Cooling English Units
TWA030CD WITH TWE030CA4 AT 1000 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 28.8 22.6 24.4 26.1 27.8 29.2* 2.13
85 63 31.0 19.3 21.0 22.8 24.5 26.2 2.21
67 33.3 15.6 17.3 19.1 20.8 22.5 2.29
71 35.7 11.8 13.6 15.3 17.0 18.7 2.37
59 28.3 22.4 24.1 25.8 27.6 28.7* 2.24
90 63 30.4 19.1 20.8 22.5 24.2 26.0 2.32
67 32.7 15.4 17.1 18.8 20.5 22.3 2.40
71 35.1 11.6 13.3 15.0 16.8 18.5 2.48
59 27.7 22.2 23.9 25.6 27.3 28.3* 2.35
95 63 29.9 18.9 20.6 22.3 24.0 25.7 2.42
67 32.1 15.2 16.9 18.6 20.3 22.0 2.51
71 34.4 11.4 13.1 14.8 16.5 18.2 2.59
59 27.0 21.9 23.6 25.3 27.1* 27.7* 2.46
100 63 29.1 18.5 20.3 22.0 23.7 25.4 2.54
67 31.3 14.8 16.6 18.3 20.0 21.7 2.62
71 33.5 11.1 12.8 14.5 16.2 17.9 2.70
59 26.3 21.6 23.3 25.0 26.5* 27.2* 2.57
105 63 28.3 18.2 20.0 21.7 23.4 25.1 2.65
67 30.4 14.5 16.2 18.0 19.7 21.4 2.73
71 32.6 10.7 12.5 14.2 15.9 17.6 2.81
59 24.9 21.0 22.7 24.4 25.4* 26.0* 2.80
115 63 26.8 17.6 19.3 21.1 22.8 24.5 2.87
67 28.8 13.9 15.6 17.3 19.1 20.8 2.95
71 30.8 10.1 11.8 13.6 15.3 17.0 3.02
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 875 1125
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.05
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 32200 BTUH
AIRFLOW = 1000 CFM
COMPRESSOR POWER = 2505 WATTS
I.D. FAN POWER = 440 WATTS
O.D. FAN POWER = 214 WATTS
E.E.R. = 9.55 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWA030CD WITH TWE040CA4-B AT 1100 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 30.8 25.2 27.1 29.1 31.0* 31.7* 2.21
85 63 33.0 21.2 23.2 25.2 27.2 29.2 2.29
67 35.4 16.9 18.9 20.9 22.9 24.9 2.37
71 37.9 12.5 14.5 16.5 18.5 20.5 2.45
59 30.1 24.9 26.9 28.9 30.5* 31.2* 2.32
90 63 32.3 21.0 23.0 24.9 26.9 28.9 2.40
67 34.7 16.7 18.6 20.6 22.6 24.6 2.48
71 37.0 12.3 14.2 16.2 18.2 20.2 2.56
59 29.5 24.6 26.6 28.6 29.9* 30.6* 2.43
95 63 31.6 20.7 22.7 24.7 26.7 28.6 2.51
67 33.9 16.4 18.4 20.4 22.3 24.3 2.59
71 36.2 12.0 14.0 16.0 17.9 19.9 2.67
59 28.6 24.2 26.2 28.2 29.3* 29.9* 2.54
100 63 30.8 20.3 22.3 24.3 26.3 28.3 2.62
67 32.9 16.0 18.0 20.0 22.0 24.0 2.70
71 35.2 11.6 13.6 15.6 17.6 19.6 2.78
59 27.8 23.9 25.9 27.9* 28.6* 29.2* 2.66
105 63 29.9 20.0 22.0 23.9 25.9 27.9 2.73
67 32.0 15.7 17.6 19.6 21.6 23.6 2.81
71 34.2 11.3 13.2 15.2 17.2 19.2 2.90
59 26.2 23.2 25.2 26.5* 27.2* 27.8* 2.89
115 63 28.1 19.3 21.2 23.2 25.2 27.2 2.96
67 30.1 14.9 16.9 18.9 20.9 22.9 3.04
71 32.1 10.6 12.5 14.5 16.5 18.5 3.11
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 975 1275
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.07
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 34100 BTUH
AIRFLOW = 1125 CFM
COMPRESSOR POWER = 2594 WATTS
I.D. FAN POWER = 300 WATTS
O.D. FAN POWER = 214 WATTS
E.E.R. = 10.45 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWA040CD WITH TWE040CA4-B AT 1500 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 39.3 32.2 34.8 37.4 39.6* 40.5* 2.79
85 63 42.2 27.1 29.7 32.3 34.9 37.4 2.90
67 45.2 21.5 24.1 26.7 29.3 31.8 3.01
71 48.4 15.8 18.4 21.0 23.6 26.1 3.13
59 38.5 31.9 34.4 37.0 39.0* 39.9* 2.93
90 63 41.4 26.8 29.4 32.0 34.5 37.1 3.04
67 44.3 21.2 23.8 26.4 28.9 31.5 3.16
71 47.4 15.5 18.1 20.7 23.2 25.8 3.29
59 37.7 31.5 34.1 36.7 38.4* 39.2* 3.07
95 63 40.5 26.5 29.1 31.6 34.2 36.8 3.18
67 43.4 20.9 23.5 26.0 28.6 31.2 3.31
71 46.4 15.2 17.7 20.3 22.9 25.5 3.44
59 36.7 31.1 33.7 36.3 37.5* 38.4* 3.21
100 63 39.4 26.0 28.6 31.2 33.8 36.4 3.33
67 42.3 20.5 23.0 25.6 28.2 30.8 3.46
71 45.2 14.7 17.3 19.9 22.5 25.1 3.59
59 35.7 30.7 33.3 35.9* 36.7* 37.6* 3.36
105 63 38.4 25.6 28.2 30.8 33.4 35.9 3.48
67 41.1 20.0 22.6 25.2 27.8 30.3 3.61
71 44.0 14.3 16.9 19.5 22.1 24.6 3.75
59 33.7 29.9 32.4 34.2* 35.0* 35.9* 3.65
115 63 36.2 24.8 27.4 29.9 32.5 35.1 3.78
67 38.8 19.2 21.8 24.3 26.9 29.5 3.92
71 41.5 13.5 16.1 18.6 21.2 23.8 4.06
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1325 1700
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 43500 BTUH
AIRFLOW = 1500 CFM
COMPRESSOR POWER = 3309 WATTS
I.D. FAN POWER = 420 WATTS
O.D. FAN POWER = 244 WATTS
E.E.R. = 10.45 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 1-1/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
