TWE5-PRC001-EN-10-15-99 13
TWA030CD WITH TWE030CA4 AT 1698 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 8.4 6.6 7.1 7.6 8.1 8.6* 2.1
29.4 17.2 9.1 5.7 6.2 6.7 7.2 7.7 2.2
19.4 9.8 4.6 5.1 5.6 6.1 6.6 2.3
21.7 10.5 3.5 4.0 4.5 5.0 5.5 2.4
15.0 8.3 6.6 7.1 7.6 8.1 8.4* 2.2
32.2 17.2 8.9 5.6 6.1 6.6 7.1 7.6 2.3
19.4 9.6 4.5 5.0 5.5 6.0 6.5 2.4
21.7 10.3 3.4 3.9 4.4 4.9 5.4 2.5
15.0 8.1 6.5 7.0 7.5 8.0 8.3* 2.3
35.0 17.2 8.8 5.5 6.0 6.5 7.0 7.5 2.4
19.4 9.4 4.5 5.0 5.4 5.9 6.4 2.5
21.7 10.1 3.3 3.8 4.3 4.8 5.3 2.6
15.0 7.9 6.4 6.9 7.4 7.9* 8.1* 2.5
37.8 17.2 8.5 5.4 5.9 6.4 6.9 7.4 2.5
19.4 9.2 4.3 4.9 5.4 5.9 6.4 2.6
21.7 9.8 3.3 3.8 4.2 4.7 5.2 2.7
15.0 7.7 6.3 6.8 7.3 7.8* 8.0* 2.6
40.6 17.2 8.3 5.3 5.9 6.4 6.9 7.4 2.7
19.4 8.9 4.2 4.7 5.3 5.8 6.3 2.7
21.7 9.6 3.1 3.7 4.2 4.7 5.2 2.8
15.0 7.3 6.2 6.7 7.1 7.4* 7.6* 2.8
46.1 17.2 7.9 5.2 5.7 6.2 6.7 7.2 2.9
19.4 8.4 4.1 4.6 5.1 5.6 6.1 3.0
21.7 9.0 3.0 3.5 4.0 4.5 5.0 3.0
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1486 1910
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.05
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 9.43 KW
AIRFLOW = 1698 CMH
COMPRESSOR POWER = 2505 WATTS
I.D. FAN POWER = 440 WATTS
O.D. FAN POWER = 214 WATTS
E.E.R. = 9.55 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 22 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
Performance
Data Cooling Metric Units
TWA030CD WITH TWE040CA4-B AT 1868 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 9.0 7.4 7.9 8.5 9.1* 9.3* 2.2
29.4 17.2 9.7 6.2 6.8 7.4 8.0 8.6 2.3
19.4 10.4 5.0 5.5 6.1 6.7 7.3 2.4
21.7 11.1 3.7 4.2 4.8 5.4 6.0 2.5
15.0 8.8 7.3 7.9 8.5 8.9* 9.1* 2.3
32.2 17.2 9.5 6.2 6.7 7.3 7.9 8.5 2.4
19.4 10.2 4.9 5.4 6.0 6.6 7.2 2.5
21.7 10.8 3.6 4.2 4.7 5.3 5.9 2.6
15.0 8.6 7.2 7.8 8.4 8.8* 9.0* 2.4
35.0 17.2 9.3 6.1 6.7 7.2 7.8 8.4 2.5
19.4 9.9 4.8 5.4 6.0 6.5 7.1 2.6
21.7 10.6 3.5 4.1 4.7 5.2 5.8 2.7
15.0 8.4 7.1 7.7 8.3 8.6* 8.8* 2.5
37.8 17.2 9.0 5.9 6.5 7.1 7.7 8.3 2.6
19.4 9.6 4.7 5.3 5.9 6.4 7.0 2.7
21.7 10.3 3.4 4.0 4.6 5.2 5.7 2.8
15.0 8.1 7.0 7.6 8.2* 8.4* 8.6* 2.7
40.6 17.2 8.8 5.9 6.4 7.0 7.6 8.2 2.7
19.4 9.4 4.6 5.2 5.7 6.3 6.9 2.8
21.7 10.0 3.3 3.9 4.5 5.0 5.6 2.9
15.0 7.7 6.8 7.4 7.8* 8.0* 8.1* 2.9
46.1 17.2 8.2 5.7 6.2 6.8 7.4 8.0 3.0
19.4 8.8 4.4 5.0 5.5 6.1 6.7 3.0
21.7 9.4 3.1 3.7 4.2 4.8 5.4 3.1
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1656 2165
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.07
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 9.99 KW
AIRFLOW = 1910 CMH
COMPRESSOR POWER = 2594 WATTS
I.D. FAN POWER = 300 WATTS
O.D. FAN POWER = 214 WATTS
E.E.R. = 10.45 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 22 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
TWA040CD WITH TWE040CA4-B AT 2547 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 11.5 9.4 10.2 11.0 11.6* 11.9* 2.8
29.4 17.2 12.4 7.9 8.7 9.5 10.2 11.0 2.9
19.4 13.2 6.3 7.1 7.8 8.6 9.3 3.0
21.7 14.2 4.6 5.4 6.2 6.9 7.6 3.1
15.0 11.3 9.3 10.1 10.8 11.4* 11.7* 2.9
32.2 17.2 12.1 7.9 8.6 9.4 10.1 10.9 3.0
19.4 13.0 6.2 7.0 7.7 8.5 9.2 3.2
21.7 13.9 4.5 5.3 6.1 6.8 7.6 3.3
15.0 11.0 9.2 10.0 10.8 11.3* 11.5* 3.1
35.0 17.2 11.9 7.8 8.5 9.3 10.0 10.8 3.2
19.4 12.7 6.1 6.9 7.6 8.4 9.1 3.3
21.7 13.6 4.5 5.2 5.9 6.7 7.5 3.4
15.0 10.8 9.1 9.9 10.6 11.0* 11.3* 3.2
37.8 17.2 11.5 7.6 8.4 9.1 9.9 10.7 3.3
19.4 12.4 6.0 6.7 7.5 8.3 9.0 3.5
21.7 13.2 4.3 5.1 5.8 6.6 7.4 3.6
15.0 10.5 9.0 9.8 10.5* 10.8* 11.0* 3.4
40.6 17.2 11.3 7.5 8.3 9.0 9.8 10.5 3.5
19.4 12.0 5.9 6.6 7.4 8.1 8.9 3.6
21.7 12.9 4.2 5.0 5.7 6.5 7.2 3.8
15.0 9.9 8.8 9.5 10.0* 10.3* 10.5* 3.7
46.1 17.2 10.6 7.3 8.0 8.8 9.5 10.3 3.8
19.4 11.4 5.6 6.4 7.1 7.9 8.6 3.9
21.7 12.2 4.0 4.7 5.4 6.2 7.0 4.1
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 2250 2887
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 12.75 KW
AIRFLOW = 2547 CMH
COMPRESSOR POWER = 3309 WATTS
I.D. FAN POWER = 420 WATTS
O.D. FAN POWER = 244 WATTS
E.E.R. = 10.45 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 28.6 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
