26 TWE5-PRC001-EN-10-15-99
Performance
Data
Air Pressure Drop (Inches) - Electric Heaters
Pressure Drop For Electric Heaters In Air Handler Models
NUMBER OF RACKS
12 34 5
AIRFLOW AIRFLOW AIR PRESSURE DROP
CFM CMH IN. W.G. (PASCALS)
600 1018.8 0.01 (2.5) 0.02 (5.0) 0.02 (5.0)
700 1188.6 0.01 (2.5) 0.02 (5.0) 0.02 (5.0)
800 1358.4 0.02 (5.0) 0.03 (7.5) 0.03 (7.5) 0.04 (10.0)
900 1528.2 0.03 (7.5) 0.03 (7.5) 0.04 (10.0) 0.05 (12.5)
1000 1698.0 0.04 (10.0) 0.04 (10.0) 0.05 (12.5) 0.06 (14.9)
1100 1867.8 0.04 (10.0) 0.05 (12.5) 0.06 (14.9) 0.07 (17.4) 0.08 (19.9)
1200 2037.6 0.05 (12.5) 0.06 (14.9) 0.07 (17.4) 0.08 (19.9) 0.09 (22.4)
1300 2207.4 0.06 (14.9) 0.07 (17.4) 0.08 (19.9) 0.09 (22.4) 0.11 (27.4)
1400 2377.2 0.07 (17.4) 0.08 (19.9) 0.10 (24.9) 0.11 (27.4) 0.13 (32.4)
1500 2547.0 0.08 (19.9) 0.09 (22.4) 0.11 (27.4) 0.13 (32.4) 0.15 (37.4)
1600 2716.8 0.09 (22.4) 0.10 (24.9) 0.12 (29.9) 0.15 (37.4) 0.17 (42.3)
1700 2886.6 0.10 (24.9) 0.11 (27.4) 0.14 (34.9) 0.17 (42.3) 0.19 (47.3)
1800 3056.4 0.11 (27.4) 0.13 (32.4) 0.16 (39.9) 0.19 (47.3) 0.21 (52.3)
1900 3226.2 0.13 (32.4) 0.15 (37.4) 0.18 (44.8) 0.21 (52.3) 0.23 (57.3)
2000 3396.0 0.14 (34.9) 0.17 (42.3) 0.20 (49.8) 0.23 (57.3) 0.26 (64.8)
NOTES:
1. See Product Data or Air Handler nameplate for approved combinations of Air Handlers and Heaters.
2. Heater model numbers may have additional suffix digits.
HEATER RACKS
HEATER NO. OF
MODEL NO. RACKS
BAY96X1405 1
BAY96X1406 2
BAY96X1408 2
BAY96X1410 2
BAY96X1411 3
BAY96X1415 3
BAY96X1419 4
BAY96X1421 4
BAY96X1426 5
BAY96X3411 3
BAY96X3415 3
