TWE5-PRC001-EN-10-15-99 25
Performance
Data
Blower Performance — TWE050CA50D — Wet Coil
EXTERNAL STATIC PRESSURE INCHES OF WATER (PASCALS)
UPFLOW & DOWNFLOW (See Notes) HORIZONTAL; NO FILTER (See Notes)
220 VOLTS 220 VOLTS
CFM CMH Hl MED LO Hl MED LO
900 1528.2
950 1613.1 0.63 (156.9)
1000 1698.0 0.61 (152.0) 0.62 (154.4)
1050 1782.9 0.58 (144.5) 0.60 (149.5)
1100 1867.8 0.54 (134.5) 0.57 (142.0)
1150 1952.7 0.50 (124.6) 0.53 (132.0)
1200 2037.6 0.45 (112.1) 0.49 (122.1)
1250 2122.5 0.61 (152.0) 0.39 (97.1) 0.64 (159.4) 0.44 (109.6)
1300 2207.4 0.59 (147.0) 0.57 (142.0) 0.33 (82.2) 0.62 (154.4) 0.61 (152.0) 0.38 (94.7)
1350 2292.3 0.56 (139.5) 0.53 (132.0) 0.26 (64.8) 0.59 (147.0) 0.58 (144.5) 0.32 (79.7)
1400 2377.2 0.52 (129.5) 0.49 (122.1) 0.18 (44.8) 0.56 (139.5) 0.55 (137.0) 0.25 (62.3)
1450 2462.1 0.48 (119.6) 0.45 (112.1) 0.10 (24.9) 0.52 (129.5) 0.52 (129.5) 0.18 (44.8)
1500 2547.0 0.44 (109.6) 0.40 (99.6) 0.01 (2.5) 0.49 (122.1) 0.48 (119.6) 0.11 (27.4)
1550 2631.9 0.40 (99.6) 0.35 (87.2) 0.47 (117.1) 0.44 (109.6) 0.00 (0.0)
1600 2716.8 0.35 (87.2) 0.30 (74.7) 0.45 (112.1) 0.40 (99.6)
1650 2801.7 0.31 (77.2) 0.25 (62.3) 0.41 (102.1) 0.35 (87.2)
1700 2886.6 0.26 (64.8) 0.20 (49.8) 0.36 (89.7) 0.28 (69.7)
1750 2971.5 0.21 (52.3) 0.14 (34.9) 0.30 (74.7) 0.20 (49.8)
1800 3056.4 0.16 (39.9) 0.08 (19.9) 0.24 (59.8) 0.13 (32.4)
1850 3141.3 0.11 (27.4) 0.02 (5.0) 0.17 (42.3) 0.07 (17.4)
1900 3226.2 0.05 (12.5) 0.10 (24.9) 0.01 (2.5)
1950 3311.1 0.02 (5.0)
NOTES:
Vertical: With filter, no horizontal drip tray. Small apex baffle. Subtract 0.06" W.G. (15) for downflow.
Horizontal: As shipped, but without filter. Subtract 0.05" W.G (12.5) for horizontal left.
Evaporator Fan Performance
