Trane TWE040CA User Manual

24 TWE5-PRC001-EN-10-15-99
Performance
Data
Evaporator Fan Performance
Blower Performance — TWE030CA40B — Wet Coil
EXTERNAL STATIC PRESSURE INCHES OF WATER (PASCALS)
UPFLOW & DOWNFLOW (See Notes) HORIZONTAL; NO FILTER (See Notes)
220 VOLTS 220 VOLTS
CFM CMH Hl MED LO Hl MED LO
600 1018.8 0.72 (179.4) 0.71 (176.9)
650 1103.7 0.62 (154.4) 0.61 (152.0)
700 1188.6 0.86 (214.2) 0.51 (127.0) 0.84 (209.2) 0.50 (124.6)
750 1273.5 0.75 (186.8) 0.40 (99.6) 0.72 (179.4) 0.39 (97.1)
800 1358.4 0.89 (221.7) 0.65 (161.9) 0.29 (72.2) 0.87 (216.7) 0.62 (154.4) 0.28 (69.7)
850 1443.3 0.81 (201.8) 0.54 (134.5) 0.18 (44.8) 0.79 (196.8) 0.51 (127.0) 0.17 (42.3)
900 1528.2 0.72 (179.4) 0.43 (107.1) 0.06 (14.9) 0.69 (171.9) 0.40 (99.6) 0.08 (19.9)
950 1613.1 0.63 (156.9) 0.32 (79.7) 0.61 (152.0) 0.30 (74.7)
1000 1698.0 0.53 (132.0) 0.21 (52.3) 0.51 (127.0) 0.17 (42.3)
1050 1782.9 0.42 (104.6) 0.10 (24.9) 0.40 (99.6) 0.02 (5.0)
1100 1867.8 0.31 (77.2) 0.31 (77.2)
1150 1952.7 0.20 (49.8) 0.22 (54.8)
1200 2037.6 0.08 (19.9) 0.10 (24.9)
NOTES:
Vertical: With filter, no horizontal drip tray. Subtract 0.06" W.G. (15) for downflow.
Horizontal: As shipped, but without filter. Subtract 0.05" W.G. (12.5) for horizontal left.
Blower Performance — TWE040CA40C — Wet Coil
EXTERNAL STATIC PRESSURE INCHES OF WATER (PASCALS)
UPFLOW & DOWNFLOW (See Notes) HORIZONTAL; NO FILTER (See Notes)
220 VOLTS 220 VOLTS
CFM CMH Hl MED LO Hl MED LO
700 1188.6 0.58 (144.5)
750 1273.5 0.61 (152.0) 0.55 (137.0)
800 1358.4 0.61 (152.0) 0.58 (144.5) 0.52 (129.5) 0.58 (144.5)
850 1443.3 0.57 (142.0) 0.54 (134.5) 0.48 (119.6) 0.52 (129.5)
900 1528.2 0.53 (132.0) 0.51 (127.0) 0.44 (109.6) 0.49 (122.1)
950 1613.1 0.49 (122.1) 0.47 (117.1) 0.40 (99.6) 0.57 (142.0) 0.45 (112.1)
1000 1698.0 0.45 (112.1) 0.43 (107.1) 0.34 (84.7) 0.53 (132.0) 0.50 (124.6) 0.40 (99.6)
1050 1782.9 0.40 (99.6) 0.38 (94.7) 0.28 (69.7) 0.48 (119.6) 0.45 (112.1) 0.35 (87.2)
1100 1867.8 0.36 (89.7) 0.34 (84.7) 0.22 (54.8) 0.43 (107.1) 0.40 (99.6) 0.30 (74.7)
1150 1952.7 0.31 (77.2) 0.29 (72.2) 0.15 (37.4) 0.39 (97.1) 0.37 (92.2) 0.22 (54.8)
1200 2037.6 0.26 (64.8) 0.24 (59.8) 0.08 (19.9) 0.35 (87.2) 0.32 (79.7) 0.17 (42.3)
1250 2122.5 0.21 (52.3) 0.18 (44.8) 0.00 (0.0) 0.31 (77.2) 0.28 (69.7) 0.10 (24.9)
1300 2207.4 0.17 (42.3) 0.13 (32.4) 0.26 (64.8) 0.22 (54.8) 0.01 (2.5)
1350 2292.3 0.11 (27.4) 0.07 (17.4) 0.21 (52.3) 0.18 (44.8)
1400 2377.2 0.06 (14.9) 0.01 (2.5) 0.15 (37.4) 0.12 (29.9)
1450 2462.1 0.01 (2.5) 0.11 (27.4) 0.08 (19.9)
1500 2547.0 0.00 0.05 (12.5) 0.02 (5.0)
NOTES:
Vertical: With filter, no horizontal drip tray. Small apex baffle. Subtract 0.06" W.G. (15) for downflow.
Horizontal: As shipped, but without filter. Subtract 0.05" W.G. (12.5) for horizontal left.
