TWE5-PRC001-EN-10-15-99 27
Supplementary
Heaters
THESE AIR HANDLERS ARE CONVERTIBLE AND MOTOR SPEED TAPS VARY BY THE UNIT ORIENTATION.
TWE030C-Heater Model Number BAY96X
Unit 1405 1406 1408,F 1410,F 1410A 1411 1411A 1415 1419 1421 3411 3415
Position Application 4.0 KW 4.8 KW 6.4 KW 8.0 KW 8.8 KW 8.8 KW 8.8 KW 12.8 KW 16.0 KW 17.6 KW 8.8 KW 12.8 KW
Vertical A/C or Elec. Furnace LLLLLLLLLLLL
Upflow Heat Pump LLLLLLLLMMLL
Vertical A/C or Elec. Furnace LLLLLLLLLLLL
Downflow Heat Pump LLLLLLLLHHLH
Horizontal A/C or Elec. Furnace LLLLLLLLLLLL
Left Heat Pump LLLLLLLLMMLL
Horizontal A/C or Elec. Furnace LLLLLLLLLLLL
Right Heat Pump LLLLLLLLHHLL
(L) Low, (M) Medium, (H) High indicate minimum heating speed setting for blower/motor operation. 1414 and 1426 not approved for this model.
TWE040C-Heater Model Number BAY96X
Unit 1405 1406 1408,F 1410,F 1410A 1411 1411A 1415 1419 1421 3411 3415
Position Application 4.0 KW 4.8 KW 6.4 KW 8.0 KW 8.8 KW 8.8 KW 8.8 KW 12.8 KW 16.0 KW 17.6 KW 8.8 KW 12.8 KW
Vertical A/C or Elec. Furnace LLLLLLLLLLLL
Upflow Heat Pump LLLLLMMHHHMM
Vertical A/C or Elec. Furnace LLLLLLLLLLLL
Downflow Heat Pump LLLLLLLHHHLL
Horizontal A/C or Elec. Furnace LLLLLLLLLLLL
Left Heat Pump LLLLLLLHHHLL
Horizontal A/C or Elec. Furnace LLLLLLLLLLLL
Right Heat Pump LLLLLLLHHHLL
(L) Low, (M) Medium, (H) High indicate minimum heating speed setting for blower/motor operation. 1414 not approved for this model.
TWE050C-Heater Model Number BAY96X
Unit 1405 1406 1408,F 1410,F 1410A 1415 1419 1421 1426 3415
Position Application 4.0 KW 4.8 KW 6.4 KW 8.0 KW 8.8 KW 12.8 KW 16.0 KW 17.6 KW 21.6 KW 12.8 KW
Vertical A/C or Elec. Furnace — — LLLL L LLL
Upflow Heat Pump L L LLLL MMHL
Vertical A/C or Elec. Furnace — — LLLL L LLL
Downflow Heat Pump L L LLLL H HHL
Horizontal A/C or Elec. Furnace — — LLLL L LLL
Left Heat Pump L L LLLL H HHL
Horizontal A/C or Elec. Furnace — — LLLL L LLL
Right Heat Pump L L LLLL MMHL
(L) Low, (M) Medium, (H) High indicate minimum heating speed setting for blower/motor operation. 14141,A and 1414 not approved for this model.
