20 TWE5-PRC001-EN-10-15-99
Performance
Data Heating English Units
TWA030CD WITH TWE030CA4 AT 1000 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 7.48 7.28 7.18 7.08 1.69 1.76 1.79 1.83
-13 8.81 8.57 8.45 8.33 1.78 1.85 1.89 1.92
-8 10.1 9.86 9.72 9.59 1.86 1.94 1.98 2.02
-3 11.4 11.1 11.0 10.8 1.95 2.03 2.08 2.12
2 12.8 12.4 12.3 12.1 2.03 2.13 2.17 2.22
7 14.1 13.7 13.5 13.4 2.12 2.22 2.27 2.31
12 15.4 15.0 14.8 14.6 2.20 2.31 2.36 2.41
17 16.7 16.3 16.1 15.9 2.29 2.40 2.45 2.51
22 17.7 17.3 17.0 16.8 2.36 2.47 2.53 2.58
27 18.7 18.2 18.0 17.7 2.42 2.54 2.60 2.66
32 19.7 19.2 19.0 18.7 2.49 2.61 2.67 2.73
37 20.7 20.2 19.9 19.6 2.55 2.68 2.74 2.80
42 21.7 21.2 20.9 20.6 2.62 2.75 2.81 2.88
47 28.8 28.0 27.6 27.2 2.73 2.87 2.93 3.00
52 30.8 30.0 29.5 29.1 2.80 2.94 3.01 3.08
57 32.8 31.9 31.5 31.0 2.88 3.02 3.09 3.17
62 34.8 33.9 33.4 32.9 2.95 3.10 3.17 3.25
67 36.8 35.8 35.3 34.8 3.02 3.18 3.25 3.33
72 38.8 37.8 37.2 36.7 3.10 3.26 3.33 3.41
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1000 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 875 1125
HEATING CAP. X0.98 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1000 CFM
HEATING CAP. (HIGH TEMP.) = 28000 BTUH
HEATING CAP. (LOW TEMP.) = 16300 BTUH
COMPR. POWER (HIGH TEMP.) = 2212 WATTS
COMPR. POWER (LOW TEMP.) = 1745 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.86
COEFF. OF PERF. (LOW TEMP.) = 1.98
OUTDOOR FAN POWER = 214 WATTS
INDOOR FAN POWER = 440 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
TWA030CD WITH TWE040CA4-B AT 1100 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 7.58 7.37 7.26 7.16 1.49 1.56 1.59 1.63
-13 8.87 8.62 8.50 8.38 1.58 1.65 1.69 1.73
-8 10.2 9.88 9.74 9.60 1.66 1.75 1.79 1.83
-3 11.4 11.1 11.0 10.8 1.75 1.84 1.88 1.93
2 12.7 12.4 12.2 12.0 1.84 1.93 1.98 2.03
7 14.0 13.6 13.5 13.3 1.92 2.02 2.08 2.13
12 15.3 14.9 14.7 14.5 2.01 2.12 2.17 2.23
17 16.6 16.2 15.9 15.7 2.10 2.21 2.27 2.33
22 17.7 17.2 16.9 16.7 2.15 2.27 2.33 2.39
27 18.7 18.2 18.0 17.7 2.21 2.33 2.39 2.45
32 19.8 19.2 19.0 18.7 2.27 2.39 2.46 2.52
37 20.8 20.3 20.0 19.7 2.32 2.45 2.52 2.58
42 21.9 21.3 21.0 20.7 2.38 2.51 2.58 2.65
47 29.1 28.3 27.9 27.5 2.47 2.61 2.68 2.75
52 31.2 30.4 29.9 29.5 2.53 2.68 2.75 2.82
57 33.3 32.4 31.9 31.5 2.60 2.74 2.82 2.89
62 35.4 34.4 33.9 33.4 2.66 2.81 2.89 2.96
67 37.5 36.5 35.9 35.4 2.72 2.88 2.96 3.03
72 39.6 38.5 37.9 37.4 2.78 2.94 3.02 3.10
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1100 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 975 1275
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1125 CFM
HEATING CAP. (HIGH TEMP.) = 28400 BTUH
HEATING CAP. (LOW TEMP.) = 16200 BTUH
COMPR. POWER (HIGH TEMP.) = 2097 WATTS
COMPR. POWER (LOW TEMP.) = 1698 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.16
COEFF. OF PERF. (LOW TEMP.) = 2.14
OUTDOOR FAN POWER = 214 WATTS
INDOOR FAN POWER = 300 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
TWA040CD WITH TWE040CA4-B AT 1500 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 9.52 9.31 9.20 9.10 1.88 1.97 2.02 2.06
-13 11.1 10.9 10.8 10.6 1.96 2.06 2.11 2.16
-8 12.8 12.5 12.3 12.2 2.04 2.14 2.20 2.25
-3 14.4 14.1 13.9 13.7 2.12 2.23 2.29 2.35
2 16.0 15.6 15.5 15.3 2.20 2.32 2.38 2.44
7 17.6 17.2 17.0 16.9 2.28 2.41 2.47 2.54
12 19.2 18.8 18.6 18.4 2.36 2.49 2.56 2.63
17 20.8 20.4 20.2 20.0 2.44 2.58 2.65 2.72
22 22.2 21.7 21.5 21.3 2.52 2.67 2.75 2.82
27 23.6 23.1 22.8 22.6 2.61 2.76 2.84 2.92
32 24.9 24.4 24.1 23.9 2.69 2.86 2.94 3.02
37 26.3 25.7 25.4 25.2 2.78 2.95 3.03 3.11
42 27.7 27.1 26.8 26.5 2.87 3.04 3.12 3.21
47 36.6 35.8 35.4 35.0 3.09 3.28 3.37 3.46
52 39.2 38.4 37.9 37.5 3.20 3.39 3.49 3.59
57 41.9 40.9 40.5 40.0 3.30 3.51 3.61 3.71
62 44.5 43.5 43.0 42.5 3.41 3.62 3.73 3.83
67 47.1 46.1 45.5 45.0 3.52 3.74 3.85 3.96
72 49.7 48.6 48.1 47.5 3.63 3.85 3.97 4.08
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1500 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1325 1700
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1500 CFM
HEATING CAP. (HIGH TEMP.) = 35800 BTUH
HEATING CAP. (LOW TEMP.) = 20400 BTUH
COMPR. POWER (HIGH TEMP.) = 2612 WATTS
COMPR. POWER (LOW TEMP.) = 1918 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.32
OUTDOOR FAN POWER = 244 WATTS
INDOOR FAN POWER = 420 WATTS
NOTE: RATED WITH 25 FEET OF 1-1/8
SUCTION AND 3/8 LIQUID LINE
