Trane TWE040CA User Manual

TWE5-PRC001-EN-10-15-99 21
Performance
Data Heating Metric Units
TWA030CD WITH TWE030CA4 AT 1698 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 2.2 2.1 2.1 2.1 1.7 1.8 1.8 1.8
-25.0 2.6 2.5 2.5 2.4 1.8 1.9 1.9 1.9
-22.2 3.0 2.9 2.8 2.8 1.9 1.9 2.0 2.0
-19.4 3.3 3.3 3.2 3.2 2.0 2.0 2.1 2.1
-16.7 3.8 3.6 3.6 3.5 2.0 2.1 2.2 2.2
-13.9 4.1 4.0 4.0 3.9 2.1 2.2 2.3 2.3
-11.1 4.5 4.4 4.3 4.3 2.2 2.3 2.4 2.4
-8.3 4.9 4.8 4.7 4.7 2.3 2.4 2.5 2.5
-5.6 5.2 5.1 5.0 4.9 2.4 2.5 2.5 2.6
-2.8 5.5 5.3 5.3 5.2 2.4 2.5 2.6 2.7
0.0 5.8 5.6 5.6 5.5 2.5 2.6 2.7 2.7
2.8 6.1 5.9 5.8 5.7 2.5 2.7 2.7 2.8
5.6 6.4 6.2 6.1 6.0 2.6 2.8 2.8 2.9
8.3 8.4 8.2 8.1 8.0 2.7 2.9 2.9 3.0
11.1 9.0 8.8 8.6 8.5 2.8 2.9 3.0 3.1
13.9 9.6 9.3 9.2 9.1 2.9 3.0 3.1 3.2
16.7 10.2 9.9 9.8 9.6 3.0 3.1 3.2 3.3
19.4 10.8 10.5 10.3 10.2 3.0 3.2 3.3 3.3
22.2 11.4 11.1 10.9 10.8 3.1 3.3 3.3 3.4
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1698 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1486 1910
HEATING CAP. X0.98 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 1698 CMH
HEATING CAP. (HIGH TEMP.) = 8.20 KW
HEATING CAP. (LOW TEMP.) = 4.78 KW
COMPR. POWER (HIGH TEMP.) = 2212 WATTS
COMPR. POWER (LOW TEMP.) = 1745 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.86
COEFF. OF PERF. (LOW TEMP.) = 1.98
OUTDOOR FAN POWER = 214 WATTS
INDOOR FAN POWER = 440 WATTS
NOTE: RATED WITH 7.62 METERS OF 22 MM
SUCTION AND 9.5 MM LIQUID LINE
TWA030CD WITH TWE040CA4-B AT 1868 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 2.2 2.2 2.1 2.1 1.5 1.6 1.6 1.6
-25.0 2.6 2.5 2.5 2.5 1.6 1.6 1.7 1.7
-22.2 3.0 2.9 2.9 2.8 1.7 1.8 1.8 1.8
-19.4 3.3 3.3 3.2 3.2 1.8 1.8 1.9 1.9
-16.7 3.7 3.6 3.6 3.5 1.8 1.9 2.0 2.0
-13.9 4.1 4.0 4.0 3.9 1.9 2.0 2.1 2.1
-11.1 4.5 4.4 4.3 4.2 2.0 2.1 2.2 2.2
-8.3 4.9 4.7 4.7 4.6 2.1 2.2 2.3 2.3
-5.6 5.2 5.0 5.0 4.9 2.2 2.3 2.3 2.4
-2.8 5.5 5.3 5.3 5.2 2.2 2.3 2.4 2.5
0.0 5.8 5.6 5.6 5.5 2.3 2.4 2.5 2.5
2.8 6.1 5.9 5.9 5.8 2.3 2.5 2.5 2.6
5.6 6.4 6.2 6.2 6.1 2.4 2.5 2.6 2.7
8.3 8.5 8.3 8.2 8.1 2.5 2.6 2.7 2.8
11.1 9.1 8.9 8.8 8.6 2.5 2.7 2.8 2.8
13.9 9.8 9.5 9.3 9.2 2.6 2.7 2.8 2.9
16.7 10.4 10.1 9.9 9.8 2.7 2.8 2.9 3.0
19.4 11.0 10.7 10.5 10.4 2.7 2.9 3.0 3.0
22.2 11.6 11.3 11.1 11.0 2.8 2.9 3.0 3.1
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1868 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1656 2165
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 1910 CMH
HEATING CAP. (HIGH TEMP.) = 8.32 KW
HEATING CAP. (LOW TEMP.) = 4.75 KW
COMPR. POWER (HIGH TEMP.) = 2097 WATTS
COMPR. POWER (LOW TEMP.) = 1698 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.16
COEFF. OF PERF. (LOW TEMP.) = 2.14
OUTDOOR FAN POWER = 214 WATTS
INDOOR FAN POWER = 300 WATTS
NOTE: RATED WITH 7.62 METERS OF 22 MM
SUCTION AND 9.5 MM LIQUID LINE
TWA040CD WITH TWE040CA4-B AT 2547 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 2.8 2.7 2.7 2.7 1.9 2.0 2.0 2.1
-25.0 3.3 3.2 3.2 3.1 2.0 2.1 2.1 2.2
-22.2 3.8 3.7 3.6 3.6 2.0 2.1 2.2 2.3
-19.4 4.2 4.1 4.1 4.0 2.1 2.2 2.3 2.3
-16.7 4.7 4.6 4.5 4.5 2.2 2.3 2.4 2.4
-13.9 5.2 5.0 5.0 5.0 2.3 2.4 2.5 2.5
-11.1 5.6 5.5 5.4 5.4 2.4 2.5 2.6 2.6
-8.3 6.1 6.0 5.9 5.9 2.4 2.6 2.7 2.7
-5.6 6.5 6.4 6.3 6.2 2.5 2.7 2.8 2.8
-2.8 6.9 6.8 6.7 6.6 2.6 2.8 2.8 2.9
0.0 7.3 7.1 7.1 7.0 2.7 2.9 2.9 3.0
2.8 7.7 7.5 7.4 7.4 2.8 3.0 3.0 3.1
5.6 8.1 7.9 7.9 7.8 2.9 3.0 3.1 3.2
8.3 10.7 10.5 10.4 10.3 3.1 3.3 3.4 3.5
11.1 11.5 11.3 11.1 11.0 3.2 3.4 3.5 3.6
13.9 12.3 12.0 11.9 11.7 3.3 3.5 3.6 3.7
16.7 13.0 12.7 12.6 12.5 3.4 3.6 3.7 3.8
19.4 13.8 13.5 13.3 13.2 3.5 3.7 3.8 4.0
22.2 14.6 14.2 14.1 13.9 3.6 3.8 4.0 4.1
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 2547 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 2250 2887
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 2547 CMH
HEATING CAP. (HIGH TEMP.) = 10.49 KW
HEATING CAP. (LOW TEMP.) = 5.98 KW
COMPR. POWER (HIGH TEMP.) = 2612 WATTS
COMPR. POWER (LOW TEMP.) = 1918 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.32
OUTDOOR FAN POWER = 244 WATTS
INDOOR FAN POWER = 420 WATTS
NOTE: RATED WITH 7.62 METERS OF 28.6 MM
SUCTION AND 9.5 MM LIQUID LINE
