TWE5-PRC001-EN-10-15-99 23
Performance
Data Heating Metric Units
TWA040CD WITH TWE050CA5-C AT 2547 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 2.8 2.8 2.7 2.7 1.9 2.0 2.1 2.1
-25.0 3.3 3.3 3.2 3.2 2.0 2.1 2.2 2.2
-22.2 3.8 3.7 3.7 3.6 2.1 2.2 2.3 2.3
-19.4 4.3 4.2 4.2 4.1 2.2 2.3 2.4 2.4
-16.7 4.8 4.7 4.6 4.6 2.3 2.4 2.5 2.5
-13.9 5.2 5.2 5.1 5.0 2.3 2.5 2.5 2.6
-11.1 5.7 5.6 5.6 5.5 2.4 2.6 2.6 2.7
-8.3 6.2 6.1 6.0 6.0 2.5 2.7 2.7 2.8
-5.6 6.6 6.5 6.4 6.3 2.6 2.7 2.8 2.9
-2.8 7.0 6.9 6.8 6.7 2.7 2.8 2.9 3.0
0.0 7.4 7.2 7.1 7.1 2.8 2.9 3.0 3.1
2.8 7.8 7.6 7.5 7.4 2.8 3.0 3.1 3.2
5.6 8.1 8.0 7.9 7.8 2.9 3.1 3.2 3.3
8.3 10.9 10.7 10.5 10.4 3.1 3.3 3.4 3.5
11.1 11.7 11.4 11.3 11.2 3.2 3.4 3.5 3.6
13.9 12.5 12.2 12.0 11.9 3.3 3.5 3.6 3.8
16.7 13.2 13.0 12.8 12.7 3.4 3.7 3.8 3.9
19.4 14.0 13.7 13.6 13.4 3.5 3.8 3.9 4.0
22.2 14.8 14.5 14.3 14.2 3.7 3.9 4.0 4.1
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 2547 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 2250 2887
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 2547 CMH
HEATING CAP. (HIGH TEMP.) = 10.67 KW
HEATING CAP. (LOW TEMP.) = 6.09 KW
COMPR. POWER (HIGH TEMP.) = 2566 WATTS
COMPR. POWER (LOW TEMP.) = 1900 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.30
OUTDOOR FAN POWER = 244 WATTS
INDOOR FAN POWER = 510 WATTS
NOTE: RATED WITH 7.62 METERS OF 28.6 MM
SUCTION AND 9.5 MM LIQUID LINE
TWA050CD WITH TWE050CA5-C AT 3057 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 3.7 3.6 3.5 3.5 2.5 2.6 2.7 2.7
-25.0 4.4 4.3 4.2 4.2 2.6 2.7 2.8 2.8
-22.2 5.1 5.0 4.9 4.8 2.7 2.8 2.9 2.9
-19.4 5.8 5.6 5.6 5.5 2.8 2.9 3.0 3.0
-16.7 6.4 6.3 6.2 6.2 2.9 3.0 3.1 3.2
-13.9 7.1 7.0 6.9 6.9 3.0 3.1 3.2 3.3
-11.1 7.9 7.7 7.6 7.5 3.1 3.2 3.3 3.4
-8.3 8.6 8.4 8.3 8.2 3.2 3.3 3.4 3.5
-5.6 8.8 8.6 8.6 8.5 3.3 3.4 3.5 3.6
-2.8 9.1 8.9 8.8 8.7 3.3 3.5 3.6 3.7
0.0 9.4 9.2 9.1 9.0 3.4 3.6 3.7 3.8
2.8 9.7 9.5 9.4 9.3 3.5 3.7 3.8 3.9
5.6 10.0 9.8 9.7 9.6 3.6 3.8 3.9 4.0
8.3 14.1 13.8 13.6 13.5 4.0 4.2 4.3 4.4
11.1 15.0 14.7 14.5 14.4 4.1 4.4 4.5 4.6
13.9 15.9 15.6 15.4 15.2 4.3 4.5 4.7 4.8
16.7 16.8 16.5 16.3 16.1 4.4 4.7 4.8 4.9
19.4 17.8 17.4 17.2 17.0 4.6 4.8 5.0 5.1
22.2 18.7 18.3 18.0 17.8 4.7 5.0 5.1 5.3
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 3057 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 2675 3439
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 3057 CMH
HEATING CAP. (HIGH TEMP.) = 13.77 KW
HEATING CAP. (LOW TEMP.) = 8.38 KW
COMPR. POWER (HIGH TEMP.) = 3222 WATTS
COMPR. POWER (LOW TEMP.) = 2313 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.24
COEFF. OF PERF. (LOW TEMP.) = 2.50
OUTDOOR FAN POWER = 255 WATTS
INDOOR FAN POWER = 750 WATTS
NOTE: RATED WITH 7.62 METERS OF 28.6 MM
SUCTION AND 9.5 MM LIQUID LINE
TWA060CD WITH TWE050CA5-C AT 3057 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 4.1 4.0 4.0 4.0 3.2 3.4 3.4 3.5
-25.0 5.0 4.9 4.8 4.8 3.4 3.5 3.6 3.6
-22.2 5.8 5.7 5.6 5.6 3.5 3.6 3.7 3.8
-19.4 6.6 6.5 6.4 6.4 3.6 3.8 3.8 3.9
-16.7 7.4 7.3 7.3 7.2 3.7 3.9 4.0 4.1
-13.9 8.3 8.1 8.1 8.0 3.9 4.0 4.1 4.2
-11.1 9.1 9.0 8.9 8.8 4.0 4.2 4.3 4.4
-8.3 10.0 9.8 9.7 9.6 4.1 4.3 4.4 4.5
-5.6 10.5 10.3 10.2 10.1 4.5 4.7 4.8 4.9
-2.8 11.0 10.8 10.7 10.6 4.9 5.2 5.3 5.4
0.0 11.5 11.3 11.2 11.1 5.3 5.6 5.7 5.8
2.8 12.0 11.8 11.7 11.6 5.7 6.0 6.2 6.3
5.6 12.5 12.3 12.2 12.1 6.1 6.4 6.6 6.8
8.3 15.8 15.5 15.4 15.3 5.3 5.6 5.7 5.8
11.1 16.8 16.5 16.3 16.2 5.5 5.8 5.9 6.1
13.9 17.8 17.4 17.3 17.1 5.7 6.0 6.2 6.3
16.7 18.7 18.4 18.3 18.1 5.9 6.2 6.4 6.5
19.4 19.7 19.4 19.2 19.0 6.1 6.4 6.6 6.8
22.2 20.7 20.3 20.1 20.0 6.3 6.7 6.8 7.0
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 3057 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 2675 3439
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 3057 CMH
HEATING CAP. (HIGH TEMP.) = 15.53 KW
HEATING CAP. (LOW TEMP.) = 9.79 KW
COMPR. POWER (HIGH TEMP.) = 4446 WATTS
COMPR. POWER (LOW TEMP.) = 3166 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.76
COEFF. OF PERF. (LOW TEMP.) = 2.26
OUTDOOR FAN POWER = 395 WATTS
INDOOR FAN POWER = 750 WATTS
NOTE: RATED WITH 7.62 METERS OF 28.6 MM
SUCTION AND 9.5 MM LIQUID LINE
