Performance
Data
(12½ Ton)
Table PD-2 — Gross Cooling Capacities (MBh) 12½ Ton Horizontal Three Phase WCH150B
Ambient Temperature (F)
85 95 105 115
Enter.
Dry Entering Wet Bulb (F)
CFM Bulb 61 67 73 61 67 73 61 67 73 61 67 73
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75 140.0 113.0 153.0 91.1 159.0 58.0 128.0 106.0 149.0 83.3 160.0 56.2 116.0 100.0 137.0 82.9 157.0 53.5 104.0 93.5 124.0 76.7 147.0 48.9
4500 80 141.0 134.0 154.0 105.0 160.0 78.3 130.0 128.0 149.0 104.0 161.0 77.5 119.0 119.0 138.0 98.4 157.0 74.3 109.0 109.0 124.0 91.9 148.0 69.6
85 146.0 146.0 155.0 124.0 161.0 94.3 139.0 139.0 149.0 125.0 162.0 96.0 129.0 129.0 138.0 119.0 158.0 95.0 119.0 119.0 125.0 113.0 148.0 90.2
90 153.0 153.0 156.0 143.0 163.0 110.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 115.0 130.0 130.0 129.0 129.0 148.0 111.0
75 143.0 119.0 154.0 93.3 160.0 59.0 132.0 113.0 151.0 86.8 161.0 57.4 119.0 106.0 141.0 88.2 159.0 54.7 107.0 99.8 127.0 81.8 151.0 50.8
5000 80 145.0 142.0 156.0 109.0 162.0 79.9 134.0 134.0 152.0 109.0 162.0 79.6 124.0 124.0 141.0 104.0 159.0 77.3 114.0 114.0 128.0 97.7 151.0 72.9
85 150.0 150.0 157.0 129.0 164.0 96.6 145.0 145.0 152.0 131.0 164.0 98.7 135.0 135.0 142.0 127.0 160.0 99.1 125.0 125.0 129.0 121.0 151.0 95.5
90 156.0 156.0 158.0 149.0 164.0 112.0 153.0 153.0 153.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 151.0 118.0
75 145.0 124.0 156.0 95.9 160.0 60.1 135.0 119.0 153.0 90.8 162.0 58.5 122.0 112.0 144.0 93.2 160.0 55.8 110.0 106.0 130.0 86.9 153.0 52.3
5500 80 147.0 147.0 157.0 111.0 162.0 80.8 139.0 139.0 154.0 114.0 163.0 81.0 129.0 129.0 144.0 110.0 161.0 80.1 118.0 118.0 130.0 103.0 154.0 76.0
85 154.0 154.0 158.0 133.0 164.0 97.9 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 135.0 162.0 103.0 130.0 130.0 132.0 128.0 154.0 100.0
90 159.0 159.0 160.0 153.0 166.0 115.0 157.0 157.0 157.0 157.0 167.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0
75 147.0 129.0 157.0 98.2 161.0 60.6 138.0 125.0 155.0 92.9 163.0 59.5 125.0 118.0 146.0 88.7 161.0 57.1 111.0 111.0 132.0 91.8 155.0 52.5
6000 80 150.0 150.0 158.0 114.0 163.0 81.5 144.0 144.0 156.0 118.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.3 122.0 122.0 133.0 109.0 155.0 78.8
85 156.0 156.0 160.0 136.0 165.0 99.1 153.0 153.0 157.0 143.0 166.0 103.0 145.0 145.0 148.0 142.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 105.0
90 161.0 161.0 162.0 157.0 167.0 117.0 160.0 160.0 160.0 160.0 168.0 124.0 155.0 155.0 155.0 155.0 164.0 130.0 146.0 146.0 146.0 146.0 156.0 130.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
Table PD-1 — Gross Cooling Capacities (MBh) 12½ Ton Downflow Three Phase WCD150B
Ambient Temperature (F)
85 95 105 115
Enter.
Dry Entering Wet Bulb (F)
CFM Bulb 61 67 73 61 67 73 61 67 73 61 67 73
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75 140.0 113.0 153.0 90.8 158.0 57.9 128.0 106.0 149.0 83.3 160.0 56.3 116.0 99.8 137.0 83.3 157.0 53.5 104.0 93.3 124.0 77.1 148.0 48.9
4500 80 141.0 134.0 154.0 105.0 159.0 78.3 130.0 128.0 149.0 104.0 161.0 77.4 119.0 119.0 138.0 98.3 157.0 74.3 109.0 109.0 125.0 91.8 148.0 69.6
85 146.0 146.0 155.0 124.0 160.0 94.3 139.0 139.0 150.0 125.0 162.0 95.8 129.0 129.0 138.0 119.0 158.0 94.9 119.0 119.0 125.0 113.0 148.0 90.2
90 153.0 153.0 156.0 143.0 162.0 111.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 114.0 130.0 130.0 129.0 129.0 148.0 111.0
75 143.0 119.0 154.0 93.5 159.0 59.0 132.0 113.0 152.0 87.2 161.0 57.4 119.0 106.0 141.0 88.6 159.0 54.8 107.0 99.5 127.0 82.3 151.0 50.9
5000 80 145.0 141.0 156.0 108.0 160.0 79.2 134.0 134.0 152.0 109.0 162.0 79.5 124.0 124.0 141.0 104.0 160.0 77.2 114.0 114.0 128.0 97.5 151.0 72.9
85 150.0 150.0 157.0 128.0 162.0 97.0 145.0 145.0 153.0 131.0 164.0 98.4 135.0 135.0 142.0 127.0 160.0 98.9 125.0 125.0 129.0 120.0 152.0 95.3
90 156.0 156.0 158.0 148.0 164.0 112.0 153.0 153.0 155.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 152.0 118.0
75 145.0 124.0 155.0 96.1 160.0 60.0 135.0 119.0 153.0 90.7 162.0 58.5 122.0 112.0 144.0 93.8 160.0 55.7 110.0 105.0 130.0 87.4 154.0 52.4
5500 80 147.0 147.0 157.0 111.0 162.0 80.5 139.0 139.0 154.0 113.0 163.0 80.9 129.0 129.0 144.0 110.0 161.0 79.9 118.0 118.0 131.0 103.0 154.0 75.9
85 153.0 153.0 158.0 132.0 164.0 97.4 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 134.0 162.0 102.0 130.0 130.0 132.0 128.0 154.0 100.0
90 159.0 159.0 160.0 152.0 166.0 115.0 157.0 157.0 157.0 157.0 166.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0
75 147.0 128.0 156.0 98.4 160.0 60.0 138.0 125.0 155.0 92.7 163.0 59.5 125.0 118.0 147.0 88.6 161.0 57.2 112.0 111.0 132.0 92.4 155.0 52.5
6000 80 150.0 150.0 158.0 113.0 162.0 81.2 144.0 144.0 156.0 117.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.1 122.0 122.0 133.0 108.0 156.0 78.7
85 156.0 156.0 159.0 135.0 164.0 98.4 153.0 153.0 157.0 142.0 166.0 103.0 145.0 145.0 148.0 141.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 104.0
90 160.0 160.0 161.0 156.0 166.0 116.0 160.0 160.0 160.0 160.0 167.0 123.0 155.0 155.0 155.0 155.0 165.0 129.0 146.0 146.0 146.0 146.0 157.0 130.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
