Performance
Data Heating English Units
WCC030FD00B AT 1000 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 7.94 7.70 7.57 7.45 1.62 1.69 1.72 1.75
-13 9.10 8.83 8.69 8.55 1.70 1.77 1.81 1.84
-8 10.3 9.95 9.80 9.64 1.78 1.86 1.90 1.93
-3 11.4 11.1 10.9 10.7 1.86 1.94 1.98 2.02
2 12.6 12.2 12.0 11.8 1.94 2.03 2.07 2.12
7 13.8 13.3 13.1 12.9 2.02 2.11 2.16 2.21
12 14.9 14.5 14.2 14.0 2.10 2.20 2.25 2.30
17 16.1 15.6 15.4 15.1 2.18 2.29 2.34 2.39
22 18.0 17.4 17.2 16.9 2.26 2.37 2.42 2.47
27 19.9 19.3 19.0 18.7 2.34 2.45 2.50 2.56
32 21.8 21.1 20.8 20.4 2.41 2.53 2.59 2.65
37 23.7 22.9 22.6 22.2 2.49 2.61 2.67 2.73
42 25.5 24.8 24.4 24.0 2.57 2.69 2.76 2.82
47 30.5 29.6 29.1 28.7 2.66 2.79 2.85 2.91
52 32.9 31.9 31.4 30.9 2.73 2.87 2.94 3.00
57 35.4 34.3 33.7 33.2 2.81 2.95 3.02 3.09
62 37.8 36.6 36.0 35.4 2.89 3.04 3.11 3.18
67 40.2 38.9 38.3 37.7 2.97 3.12 3.19 3.27
72 42.6 41.3 40.6 39.9 3.05 3.20 3.28 3.35
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1000 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 870 1130
HEATING CAP. X0.98 X1.02
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1000 CFM
HEATING CAP. (HIGH TEMP.) = 29600 BTUH
HEATING CAP. (LOW TEMP.) = 15600 BTUH
COMPR. POWER (HIGH TEMP.) = 2195 WATTS
COMPR. POWER (LOW TEMP.) = 1695 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.12
COEFF. OF PERF. (LOW TEMP.) = 2.00
OUTDOOR FAN POWER = 250 WATTS
INDOOR FAN POWER = 340 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
WCC040FD00B AT 1325 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 10.5 10.2 10.1 9.97 2.27 2.36 2.40 2.45
-13 12.1 11.7 11.6 11.4 2.35 2.45 2.49 2.54
-8 13.6 13.2 13.1 12.9 2.43 2.53 2.58 2.64
-3 15.1 14.7 14.5 14.3 2.51 2.62 2.67 2.73
2 16.6 16.2 16.0 15.8 2.58 2.70 2.76 2.82
7 18.2 17.7 17.5 17.3 2.66 2.79 2.85 2.91
12 19.7 19.2 19.0 18.7 2.74 2.87 2.94 3.01
17 21.2 20.7 20.4 20.2 2.82 2.96 3.03 3.10
22 23.8 23.2 22.9 22.6 2.93 3.07 3.15 3.22
27 26.4 25.8 25.4 25.1 3.04 3.19 3.26 3.34
32 29.0 28.3 27.9 27.5 3.14 3.30 3.38 3.46
37 31.6 30.8 30.4 30.0 3.25 3.42 3.50 3.58
42 34.2 33.3 32.9 32.4 3.36 3.53 3.62 3.70
47 40.5 39.4 38.9 38.3 3.48 3.66 3.75 3.84
52 43.7 42.5 41.9 41.4 3.59 3.78 3.87 3.96
57 46.9 45.6 45.0 44.4 3.70 3.89 3.99 4.09
62 50.1 48.8 48.1 47.4 3.81 4.01 4.11 4.21
67 53.3 51.9 51.2 50.4 3.92 4.13 4.23 4.33
72 56.5 55.0 54.2 53.5 4.03 4.24 4.35 4.46
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1325 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1153 1497
HEATING CAP. X0.98 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1325 CFM
HEATING CAP. (HIGH TEMP.) = 39400 BTUH
HEATING CAP. (LOW TEMP.) = 20700 BTUH
COMPR. POWER (HIGH TEMP.) = 2600 WATTS
COMPR. POWER (LOW TEMP.) = 1900 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.06
OUTDOOR FAN POWER = 500 WATTS
INDOOR FAN POWER = 560 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
WCC050FD00B AT 1675 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 14.3 13.9 13.8 13.6 2.94 3.06 3.12 3.18
-13 16.8 16.4 16.2 16.0 3.09 3.23 3.30 3.36
-8 19.4 18.9 18.7 18.4 3.25 3.40 3.47 3.55
-3 21.9 21.4 21.1 20.8 3.41 3.57 3.65 3.73
2 24.5 23.9 23.6 23.3 3.57 3.74 3.82 3.91
7 27.0 26.3 26.0 25.7 3.72 3.91 4.00 4.09
12 29.5 28.8 28.5 28.1 3.88 4.08 4.17 4.27
17 32.1 31.3 30.9 30.5 4.04 4.25 4.35 4.45
22 33.9 33.1 32.7 32.3 4.08 4.29 4.39 4.50
27 35.8 34.9 34.5 34.0 4.12 4.33 4.44 4.54
32 37.7 36.7 36.2 35.8 4.16 4.37 4.48 4.59
37 39.5 38.5 38.0 37.5 4.20 4.42 4.53 4.63
42 41.4 40.3 39.8 39.3 4.24 4.46 4.57 4.68
47 55.0 53.6 52.9 52.2 4.69 4.94 5.06 5.19
52 58.8 57.3 56.6 55.8 4.80 5.06 5.18 5.31
57 62.6 61.0 60.2 59.4 4.91 5.17 5.30 5.43
62 66.5 64.8 63.9 63.0 5.02 5.29 5.42 5.55
67 70.3 68.5 67.6 66.7 5.13 5.40 5.54 5.68
72 74.1 72.2 71.2 70.3 5.24 5.52 5.66 5.80
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1675 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1457 1893
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1675 CFM
HEATING CAP. (HIGH TEMP.) = 53600 BTUH
HEATING CAP. (LOW TEMP.) = 31300 BTUH
COMPR. POWER (HIGH TEMP.) = 3760 WATTS
COMPR. POWER (LOW TEMP.) = 3065 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.16
OUTDOOR FAN POWER = 500 WATTS
INDOOR FAN POWER = 680 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
