Trane WZS - Height Requirements; Mounting Surfaces; Address Setting

BAS-SVX04A-EN • Wireless Zone Sensor 11
Product Description
Figure 2. Mounting hole dimensions for sensor and receiver
Note: The dimensions are the
same for both the sensor
and the receiver.
3.27 in (8.30 cm)
2.36 in (6.00 cm)
1.34 in (3.41 cm)
