BAS-SVX04A-EN • Wireless Zone Sensor 9
This manual contains information about installing, operating, and maintaining
the Trane
®
Wireless Zone Sensor system.
Overview
The Trane Wireless Zone Sensor set includes a sensor and a receiver that work
together to provide the same functions as the equivalent Trane wired sensor
(#4190-1090), such as the standard 10 kΩ temperature input (with the exception of
the communication jack). No further software or hardware is necessary for site
evaluation, installation, or maintenance.
The sensor transmits the zone temperature, all zone temperature setpoint
functions, timed override Occupied (On) and timed override Unoccupied (Cancel)
information to the receiver. The receiver electrically reproduces the zone
temperature resistance, all zone temperature setpoint function resistances, and
timed override On and timed override Cancel information as sent by the sensor.
Factory or Field Installed
The information in this manual is applicable to Wireless Zone Sensor sets that
are either factory or field installed.
Part Numbers
Dimensional Diagrams
See Figure 1, p. 10 and Figure 2, p. 11 for dimensions of the Wireless Zone Sensor
set. The dimensions are the same for both the sensor and the receiver.
Product Description
Table 1. Part numbers
Part number Description
X13790496 Wireless Zone Sensor set, North America (100 mW, 16 channel),
Fahrenheit, analog
X13790498 Wireless Zone Sensor set, North America (100 mW, 16 channel),
Celsius, analog
X13790492 Sensor only, Fahrenheit
X13790494 Sensor only, Celsius
X13790488 Receiver only, North America (100 mW, 16 channels), analog
X13790489 Receiver only, Europe (10 mW, 16 channels), analog
(Not advised for North America.)
X19051672 Wire harness, five-conductor, for wireless receiver (all locations)
