48 Wireless Zone Sensor • BAS-SVX04A-EN
Specifications and Agency Compliance
Chris VanderKoy
Design/Compliance Engineer
European contact
Societe Trane (Epinal, France)
1, rue des Ameriques, B.P. 6
F-88191 Golbey Cedex, France
Phone: (33) 329.31.73.00
Fax: (33) 329.81.24.98
This document validates CE conformity of the Trane Wireless Zone Sensor system, receiver module.
Declaration of CE Conformity
for the Trane Wireless Zone Sensor system, receiver module
The manufacturer hereby declares that the product:
Conforms to the following standards or other normative documents:
When and Where Issued:
R&TTE: 3/8/2006
EMC: 3/8/2006
The mark of compliance:
Manufacturer name: Trane, a division of American Standard, Inc.
Manufacturer address: 3600 Pammel Creek Road
La Crosse, WI 54601 USA
Product name: Sensor, Temp, Wireless Receiver, 10 mW, 16 Channels, Analog, Europe
Model numbers: X13790489
R&TTE Directive:
EN 300 328 Radiated Emissions (Note: Norway and Romania have restrictions as per Annex 1
Band H of ERC/REC 70-03)
EMC Directive:
EN 301 489-1 Conducted Emissions: Clause 8.2, 8.3, 8.4, 8.7
EN61000-4-2 ESD: ± 4 kV by contact +/- 8 kV by air. Criterion B.
EN61000-4-3 Radiated RF Immunity: 10 V/m, 80% AM @ 1 kHz, 1% step of previous frequency
80–1000 MHz, 1400–2000 MHz. Criterion A.
EN61000-4-4 EFT Burst: ± 0.5 kV & ± 1 kV Power Ports. Criterion B.
EN61000-4-5 Surge: ± 0.5 kV Differential, ± 1 kV Common Mode Power Ports. Criterion A.
EN61000-4-6 Conducted Immunity: 3 V 80% AM @ 1 kHz 0.15 MHz to 80 MHz Power Ports.
Criterion A.
EN61000-4-8 Magnetic Field Immunity: 30 A/m. Criterion A.
EN61000-4-11 Voltage Dips and Interruptions: 70%, 40%, and 5% nominal for 10 mS, 100 mS,
and 5 s (50 Hz). Criterion B.
