Trane XR202 Programmable Thermostat
SPECIFICATION DESCRIPTION
Product Models TCONT202
Product XR 202
Size 3-3/4” x 6” x 1-1/8 (HxWxD)
Configurations Heat / Cool
Maximum Number of Stages 1H, 1C
Operating Temperature 32°F to 105°F (0 to +41°C) / 90% RH Non Condensing
Shipping Temperature Range -20 to 150°F (-29 to +65°C)
Input Power (DC) Two 1.5V AA Alkaline
Input Power (AC) 20 - 30 VAC, NEC Class ll, 50/60 HZ
Wire Usage 18 AWG
System Modes Heating, Cooling, Off
Fan Modes Auto, On
Cooling Setpoint Temperature Range 45°F to 99°F, 1°F resolution
Heating Setpoint Temperature Range 45°F to 99°F, 1°F resolution
Temperature Display Range 32°F to 99°F, 1°F resolution
Minimum Cycle Off Time Delay Compressor: 5 minutes, Indoor Heat; 1 minute
Terminal Load 1.0A per terminal, 1.5A maximum all terminals combined
Operating Ambient 32°F to +105°F (0° to +41°C)
Shipping Temperature Range -20°F to +150°F (29° to +65°C)
RATED DIFFERENTIALS
FAST MEDIUM SLOW
Heat (@ 6°F/Hr) 0.5°F 0.75°F 1.9°F
Cool (@ 6°F/Hr) 0.9°F 1.2°F 1.7°F
THERMOSTAT APPLICATION GUIDE
Thermostat Applications Maximum Stages Heat/Cool
Gas, Oil, Electric, (mV and 24V), Heat Only, Cool Only or Heat/Cool Systems 1/1
2. Product Specifications
3. General Information
3.1 Overview
The 202 is a programmable push button single stage
thermostat with a 3.5’’ backlit display. The 202 features a
scheduling mode that can operate a 7-day program, 5-1-1
program or operate in a non-programmable mode.
3.2 Contents
— 1-Thermostat
— 1-Sub-base
— 2-Phillips slotted head mounting screws
— 2-Nylon Drywall Anchors
— 1-Installation Guide / User Guide
3.3 Accessories
Wall Cover Plate (BAYCOVR200A)
4. Installation
4.1 Location
The 202 is designed for installation in climate controlled living
spaces. Place the unit in a central location with good circulation.
For proper temperature sensing, avoid exposing the 202 to heat
radiated from lamps, sun light, fireplaces or any other radiant heat
source.
Avoid locations close to windows, behind doors or alcoves with
poor air circulation, adjoining outside walls, or doors that lead to
the outside.
Select a location that prevents the 202 from being directly exposed
to air currents from supply registers or ceiling fans.
Mount the Control on a section of interior wall that does not
contain hot or cold water pipes or duct work.
