7.3 General Scale Operation
7.3.1Force gauge
1. Select the desired weighing unit by pressing the UNITS key.
2. If necessary, press the ZERO key to obtain a weight reading of zero.
3. Place the object to be weighed on the platter and allow the indicator to stabilize. When
the weighing unit default kN, if the item weight exceeds 9d over the system’s weight
capacity, it displays “□□□□□□”. When the weight unit is N/lbf, if the item weight doesn’t
exceed 9d over the system’s weight capacity, but the display value exceed LED’s
maximum digital, it display “□□□□□□”.
4. Read the weight shown on the display.
7.3.2 Zero & Clear
1. In general force gauge mode, the key is ZERO function key: Press the ZERO key to
obtain a weight reading of zero.
2. In keeping peak value mode, the key is CLEAR function key: Press the CLEAR key to
clear the peak value which is shown in the display, prepare to the next peak value
keeping operation.
7.3.3 Keeping Peak Value
1. Press the PEAK key to enter keeping peak value mode. The item’s weight is from 2%
to 100% of full capacity, the indicator can record the maximum value in real time.
When the weight is less 2% of full capacity, the function is unable.
2. If necessary, press CLEAR key to clear the present peak value shown in the display.
3. Press PEAK key again, exit the keeping peak value mode.
4. In calibration mode, press PEAK key to enter the present channel to set the
parameters.
7.3.4 Channel Change
1. Press CHANNEL ( ) key to change the present channel circulating. The default
channel is channel 0. When pressing the CHANNEL ( ) key, the system will automatic
delay 2—5 seconds, then enter the next channel. TI-1500B has four absolute channels for
custom using in the different load cell standard sources.
Note: In general operate mode, just using CHANNEL key to change the channels.
It’s different from using in calibration mode.
7.3.5 Print
1. This key is used to print weight information by serial printer and send weight information
out to the PC by serial port.
