1. Introduction
Product Description
Transition Networks’ managed S3290 NID provides advanced packet performance metering and service
creation aimed directly at customer premises and cell sites. The S3290 is optimized for business Ethernet
and mobile backhaul deployments.
The S3290 is a multi-service NID that provides SLA assurance and advanced fault management that is
MEF CE2.0 compliant. IEEE 802.1ag Service OAM, ITU Y.1731 Performance Monitoring and IEEE 802.3ah
Link OAM are standard features.
The S3290 supports advanced features such as IPv6 and IPv4, VLANs, QoS, bandwidth allocation, ring
protection, jumbo frames and numerous security features. The S3290 can be managed and provisioned
with Transition Networks Converge
™
EMS or via Web, CLI and SNMP (v1, v2c & v3). The S3290 supports
SSL/SSH, RADIUS, TACACS+, Management VLAN and ACL rules.
The S3290 offers AC or DC power inputs for operation in a variety of environments. The SFP ports are
triple speed and support 100Mbps, 1000Mbps or SGMII SFPs. CWDM and Bi-Di SFPs are also supported,
allowing for flexible network architectures.
Models
The S3290 models are described below.
Model
Description
S3290-24
2xTP 4xSFP NID: Two 10/100/1000Mbps RJ45 ports with four 100/1000Mbps SFP
ports. Includes IEEE 1588v2 with RFC 2544 Traffic Generation.
S3290-42
4xTP 2xSFP NID: Four 10/100/1000Mbps RJ45 ports with two 100/1000Mbps SFP
ports. Includes IEEE 1588v2 with RFC 2544 Traffic Generation.
Options
The S3290 options are listed below.
Model
Description
25132
Optional Power Supply supporting an operating environment of -30°C to 70°C.
WMBL
Wall Mount Bracket (Kit) Long.
WMBD
Wall Mount Bracket DIN (DIN Rail Vertical Wall Mount Kit).
S3290-RMB
Single Rack Mount Bracket for S3290 NID.
S3290-RPS
Isolated Wide Input 20W Power Supply Assembly for S3290 Series
SFPs
See the TN SFP webpage for models and specifications.
Applications
The S3290 is designed to support a wide range of MEF-based Carrier Ethernet services to include Fiber-to-
the-Desk, Migration to Packet Networks, Small Cell / DAS, and Cloud Services.
