2. Installation
Unpacking / Package Contents
Carefully unpack the contents and verify that you have received these items in the packaging:
• One S3290 NID
• One Power Supply (optional - ordered separately)
• One 6’ Console Cable, DB9 Female-to-RJ45 Male
• One Product Documentation Postcard
• One S3290 Quick Start Guide
• Four rubber feet
Save the packaging for future use.
Install Cautions and Warnings
Warning: Risk of Electrical Shock. Disconnect power before installing the S3290. Failure to observe
this warning could result in an electrical shock.
CAUTION Only qualified persons should install the S3290. Failure to observe this caution could
result in poor performance or damage to the equipment.
CAUTION Install the S3290 in an operating environment where the temperature range is from
-20°C to +65°C, with relative humidity of 5% to 90% non-condensing. Failure to observe this caution could
result in poor equipment performance.
CAUTION DO NOT install the S3290 in areas where strong electromagnetic fields (EMF) exist.
Failure to observe this caution could result in poor equipment performance and data corruption.
WARNING Disconnect power before installing and wiring the S3290 for power. Failure to observe this
warning could result in an electrical shock.
Attention: this product, like all electronic products, uses semiconductors that can be damaged by
ESD (electrostatic discarge). Always observe appropriate precautions when handling.
Installation Location
Deciding where to install the S3290 can greatly affect its performance. When selecting an installation
location, consider the following:
• Install the S3290 in a fairly cool and dry place. See the “Specifications” section (page 7) and the
cautions below for the acceptable temperature and humidity ranges.
• Install the S3290 where it will not be exposed to liquid.
• Install the S3290 in a location free from strong electromagnetic field generators (such as motors).
• Do not expose or subject the S3290 to excessive vibration, dust, or direct exposure to sunlight.
• Leave at least 5 cm (1.97 in) of space around the S3290 for ventilation purposes.
Desktop Installation
Attach the Rubber Feet to the bottom of the S3290 for added stability when placing on a desktop, table top,
or other flat surface. Make sure that air flow is not blocked by any obstacles.
