4-2 REEL CONTROL GROUP
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
T6-4-20000 Reel Control Group 1
T6-4-20000S
Reel Control Group (Stainless Steel Model)
1
1 T6-4-20110 Reel Unit Base 1
3 T6-4-20130 Brake Tension Holder 1
4 T6-4-20140 Brake Belt Tightener 1
T6-4-20140S
Brake Belt Tightener (Stainless Steel Model)
1
5 T6-4-20150 Reel Shaft 1
T6-4-20150S Reel Shaft (Stainless Steel Model) 1
6 T6-4-20160 Holder Shaft 2
T6-4-20160S Holder Shaft (Stainless Steel Model) 2
7 T6-4-20170 Reel Brake Arm 1
T6-4-20170S
Reel Brake Arm (Stainless Steel Model) 1
8 T6-4-20180 Brake Tension Arm Spring 1
T6-4-20180S Brake Tension Arm Spring 1
(Stainless Steel Model)
9 T6-4-20190 Brake Tension Spring Ring 1
10 BR6205ZZ Bearing, 6205ZZ 2
11 MB1525 Metal Bush, 1525 2
13 ER19 Snap Ring, E-19 1
ER19S
Snap Ring, E-19 (Stainless Steel Model) 1
14 ER12 Snap Ring, E-12 5
ER12S
Snap Ring, E-12 (Stainless Steel Model) 5
15 SR08 Stop Ring, S-8 1
SR08S Stop Ring, S-8 (Stainless Steel Model) 1
16 T6-4-20260 Spring Hook 1
17 T6-4-20270 Set Block 1
T6-4-20270S Set Block (Stainless Steel Model) 1
18 T6-4-20280 Washer 1
T6-4-20280S Washer (Stainless Steel Model) 1
19 T6-4-20290 Collar 1
20 T6-4-20300 Collar 1
21 TC-013 Inner Flange 1
23 TC-014 Outer Flange 1
24 TC-015 Protector 1
25 TC-016 Reel Nut Handle 1
27 TC-020 Pin 1
T6-4-20000
T6-4-20000S
