Contact Information
For more information about our products, please visit www.transtek.cn.you can get
customer service, usual problems and customer download, transtek will serve you
anytime.
Manufactured by:
Company:
Address:
Authorized Component
1.please use the TRANSTEK
authorized adapter
(Not included).
Guangdong Transtek Medical Electronics Co., Ltd.
Zone A, No.105 ,Dongli Road, Torch Development District,
Zhongshan,528437,Guangdong,China
Guangdong Transtek Medical Electronics Co., Ltd.
Adapter
ModelBLJ06L060100P-B
InputAC 100-240V
50/60Hz 0.2A Max
Output6V 1000mA
24
25
SPECIFICATIONS
About 22cm~42cm
Type BF applied part
WARNING: No modification of this equipment is allowed.
Power supply
Battery powered mode:
6VDC 4×AAA batteries
AC adaptor powered mode:
6V 1A (Not included)
(Please only use the recommended AC
adaptor model).
Display mode
Measurement mode
Oscillographic testing mode
Measurement range
Measurement perimeter of
the upper arm
Net Weight
Approx.252g(Excluding the dry cells and cuff)
External dimensions
Attachment
Mode of operation
Continuous operation
Degree of protection
Protection against
ingress of water
Accuracy
Normal working condition
Storage & transportation
condition
Software Version
A01
Pressure:
5-40within±0.4kPa(3mmHg)
Pulse value:±5%
Digital LCD V.A.84mm×73mm
Approx.107mm×103mm×118mm
4×AAA batteries,user manual, carry bag
Rated cuff pressure:
0mmHg~299mmHg(0kPa ~ 39.9kPa)
Measurement pressure:
SYS: 60mmHg~230mmHg (8.0kPa~30.7kPa)
DIA: 40mmHg~130mmHg (5.3kPa~17.3kPa)
Pulse value: (40-199)beat/minute
IP21 It means the device could protected
against solid foreign objects of 12.5mm and
greater, and protect against vertically falling
water drops.
Device Classification
Battery Powered Mode:
Internally Powered ME Equipment
AC Adaptor Powered Mode:
Class II ME Equipment
A temperature range of :+5°C to +40°C
A relative humidity range of 15% to 90%,
non-condensing, but not requiring a water
vapour partial pressure greater than 50 hPa
An atmospheric pressure range of :
700 hPa to 1060 hPa
Temperature:-20°C to +60°C
A relative humidity range of ≤ 93%,
non-condensing,at a water vapour pressure
up to 50hPa
AUTHORIZED COMPONENT
