7
6
LCD display signal
INTRODUCTION INTRODUCTION
CAUTION
* The plug/adapter plug pins insulates the device from the main supply. Do not position the
device in a position where it is difficult to disconnect from the supply mains to safely terminate
operation of ME equipment.
* The operator shall not touch output of batteries /adapter and the patient simultaneously.
* Cleaning :Dust environment may affect the performance of the unit. Please use the soft cloth
to clean the whole unit before and after use. Don’t use any abrasive or volatile cleaners.
* The device doesn’t need to be calibrated within two years of reliable service.
* If you have any problems with this device, such as setting up, maintaining or using, please
contact the SERVICE PERSONNEL of Transtek. Don’t open or repair the device by yourself in
the event of malfunctions. The device must only be serviced, repaired and opened by
individuals at authorized sales/service centers.
* Please report to Transtek if any unexpected operation or events occur.
* Keep the unit out of reach of infants, young children or pets to avoid inhalation or swallowing
of small parts. It is dangerous or even fatal.
* Be careful to strangulation due to cables and hoses, particularly due to excessive length.
* At least 30 min required for ME equipment to warm from the minimum storage temperature
between uses until it is ready for intended use. At least 30 min required for ME equipment to
cool from the maximum storage temperature between uses until it is ready for intended use.
* This equipment needs to be installed and put into service in accordance with the information
provided in the ACCOMPANYING DOCUMENTS;
* Wireless communications equipment such as wireless home network devices, mobile phones,
cordless telephones and their base stations, walkie-talkies can affect this equipment and should
be kept at least a distance d away from the equipment. The distance d is calculated by the
MANUFACTURER from the 80 MHz to 5.8 GHz column of Table 4 and Table 9 of IEC
60601-1-2:2014, as appropriate.
* Please use ACCESSORIES and detachable parts specified/ authorised by MANUFACTURER.
Otherwise, it may cause damage to the unit or danger to the user/patients.
* There is no luer lock connectors are used in the construction of tubing.If there has, there is a
possibility that they might be inadvertently connected to intravascular fluid systems, allowing air
to be pumped into a blood vessel.
* Please use the device under the environment which is provided in the user manual. Otherwise,
the performance and lifetime of the device will be impacted and reduced.
SYMBOL DESCRIPTION
Systolic blood pressure High blood pressure
Diastolic blood pressure Low blood pressure
EXPLANATION
mmHg
kPa
Measurement Unit of the blood pressure
Measurement Unit of the blood pressure
Low battery
Batteries are low and need to be replaced
Current Time
Month/Day/Year, Hour/Minute
User 1
Start measurement,save and transmit the
measuring results for User 1
User 2
Start measurement,save and transmit the
measuring results for User 2
The average value
The average value of the latest three
records
Pulse in beats per minutePulse display
Blood pressure monitor is detecting an
irregular heartbeat during measurement.
Blood pressure
level indicator
Indicate the blood pressure level
Heartbeat
Blood pressure monitor is detecting a
heartbeat during measurement.
(1mmHg=0.133kPa)
(1kPa=7.5mmHg)
Motion indicator
Motion may result in an inaccurate
measurement
Indicate it is in the memory mode and
which group of memory it is.
Memory
Excessive Body Motion
Detector
