6 Installation (for qualified installers only)
© Travis Industries, Inc. 4050608 100-01203_000
Installation Warnings:
! This appliance is designed for outdoor use only, in well-ventilated areas.
! Failure to follow all of the requirements may result in property damage, bodily
injury, or even death.
! This torch must be installed by a qualified installer.
! This appliance is designed to operate on natural gas, or propane (LP).
! Notify your insurance company before hooking up this appliance. All relevant
information on the Tempest Torch is located on page 2, Important Information.
You can fax them page 2.
! The requirements listed below are divided into sections. All requirements must be
met simultaneously. The order of installation is not rigid – the qualified installer
should follow the procedure best suited for the installation.
Packing List
• Main Assembly
• Burner Top
• (4) Support Bars (w screws)
• Top Plate
• Rain Cap
• 5/32” Hex Wrench
• Control Cover (pre-installed)
• (4) ¼-20 x ½” Hex Head Screws
Additional Items Required
This Torch Requires One of the Following Base Assemblies:
• Wall Mount Kit
• Post Mounting Kit
• Pier Mounting Kit
Recommended Order of Installation
1. Determine the location of the torch, making sure all clearances and requirements are met (see page 7).
2. Run the gas line and install through the post, pier, or wall mount (see the instructions included with these
kits).
3. Attach the torch assembly to the gas line and attach the torch assembly to the mount (see page 9).
4. Assemble the torch (see page 10 - attach the rain cap if desired – see page 11).
5. Bleed the gas line then start the torch (see page 14). Verify the torch works correctly and there are no gas
leaks.
6. Give this manual to the homeowner and explain operation of the torch.
