8 Installation (for qualified installers only)
© Travis Industries, Inc. 4050608 100-01203_000
Gas Line Requirements
! The gas line must be installed in accordance with all local codes or, in the absence of local
codes, with the National Fuel Gas Code, ANSI Z223.1. Consult your local gas supplier or
propane gas dealer for code regulations and recommended procedures.
! The torch and gas control valve must be disconnected from the gas supply piping during any
pressure testing of that system at test pressures in excess of 1/2 psig. For pressures less
than 1/2 psig, isolate the gas supply piping by closing the manual shut-off valve.
! Leak test all gas line joints and the gas control valve prior to and after starting the torch.
LP and NG Configuration
This torch is shipped either for natural gas or for propane. The torch is not convertible from one fuel
to another. Check the sticker on the control panel to make sure the correct fuel is used. The torch has
unique orifices and burners for each fuel. See the table below for details.
NG LP
Input Rating (Btuh) 20,000 20,000
Orifice Size (DMS) #50 #55
Burner Ports 25 Holes 49 Holes
Manifold Pressure 7" wc 11" wc
Max. Inlet Pressure 7" wc 11" wc
Gas Line Connection
A manual shutoff valve is required on the gas supply to the torch. It should be placed upstream of the flex
line. A shut-off valve is included with the optional wall-mount kit.
NOTE: This version of the tempest torch may not be connected to a portable LP cylinder.
