1 OVERVIEW: DRIVE SYSTEM
Charger
(Details from page EN-77)
E
Charger A Charger S (EU/US)
Drivepack
(Details from page EN-42)
A
Bottom Bracket
(Details from page EN-48)
B
Battery
(Details from page EN-68)
D
Battery 250 X
Battery 250
Remote b
Remote fX
Remote bX
Remote
(Details from page EN-52)
C
