Trek FAZUA - Display of Charging Level;Support Level

EN-53
| evation
7
C
Part designations
1
→
Upper button
2
→
Center button
3
→
Bottom button
4
→
LED display
5
→
Status display
6
→
Display of charging level/support level
7
→
Fixing screw remote

The numbering 1–7 within this section refers to the individual
parts of the components
C
(Remote b).
Individual parts of other components illustrated within this
section are additionally marked with the corresponding
component letter.
