24 DETAILED VIEW & PART DESIGNATIONS:
REMOTE fX AND REMOTE bX

The Remotes fX and bX differ in their attachment point:
→ Remote fX is located on the frame (top and bottom tube),
→ Remote bX is located on the handlebar.
Remote fX
Remote bX
C
2
1
3
4
5
Remote bX
2
1
3
4
5
Remote fX
C
5
6
7
