EN-23
| evation
3. Check the drivepack makes a tight fit.
If the drivepack does not lock, repeat the procedure. Do not use the
drive system if the drivepack cannot be locked to the e-bike. If the
unlocked drive unit falls out of the e-bike holder while riding, this can
lead to an accident/fall and damage the drive unit or the battery.
4.1.3 Remove drivepack from e-bike
More detailed information can be found → in chapter 15.2 "Remove drivepack from
e-bike".
WARNING
Risk of burns!
The radiator in the drivepack can become very hot during
operation so that you can burn yourself on it.
► Let the drivepack to cool down completely before touching
the drivepack.
1. Secure the drivepack with one hand.
2. Press the push button or move the locking lever upwards as far as
possible to release the drivepack from the lock.
3. Press and hold the push button and carefully lower the drivepack.
The locking lever automatically remains in the open position.
4. Remove the drivepack from the interface on the bottom bracket.
