Install
1. Put the seat in the fully reclined
position.
2. At an angle, use the lower openings to
mount the seat on the two mushroom
fasteners.
3. Push the seat frame backwards to
align the two upper holes with the
crossbar holes.
4. Install the two washers and bolts
in the crossbar. Torque the bolts to
25Nm.
WARNING: Reapply threadlocker
All reused-fasteners with pre-applied
threadlocker must be cleaned with iso-
propyl alcohol and have new threadlocker
applied before re-assembly. If threadlocker
is not applied, the fasteners may loosen
which could damage the bicycle and result
in injury to the rider.
5. Move the seat to the straight-up
position.
6. If installing both seats, put the rst
seat in the 0 degree position to best
access the fasteners for the second
seat.
