Bike diagrams
These diagrams include the basic e-cargo bike parts with original equipment only.
Rear Cargo
3
6
3
5
4
1
2
16
13
11
17
9
19
18
14
15
12
7
10
8
1 Saddle 11 Drive unit Accessories
• Family pack
• Fenders
• Front rack
• Front panniers
• Rear panniers
• Range extender battery
2 Seat post clamp 12 Chainguard
3 Brake lever 13 Chain
4 Remote 14 Kickstand
5 Smart phone grip 15 Footrest
6 Shift lever 16 Rear derailleur
7 Front light 17 Gears (cassette)
8 Frame sticker 18 Rear light
9 Battery 19 Rear rack
10 Fork stabilizer
