2024 Marlin+
12
Lower the motor
For access to routing and battery connections the motor can be lowered, rather than completely removed.
1. Remove the seat post dropper lever from the handlebar. This will create slack in the seat post dropper routing so the rout-
ing can be repositioned to allow the motor to be lowered.
2. Remove the motor guard. See Motor guard on page 10.
3. Loosen bolts
1
and
3
Remove bolt
2
.
1
2
3
4. Support the motor with one hand and use your other hand to remove bolt
3
.
5. Slowly lower the motor. The motor will hang from the frame by the remaining bolt
1
.
