2024 Marlin+
14
Remove the battery
NOTICE: Only professional bike mechanics should remove the battery.
Tip: Before beginning this procedure remove the
seat post dropper lever from the handlebar. This
will create slack in the hosing that runs under the
motor and make it easier to remove the motor.
1
2
3
Rotate the bike in the stand so the
headtube is lower than the motor
cavity, This will prevent the battery
from sliding out of the frame in
the next step.
4
5
The battery is now loose in the frame. Place one hand
below the downtube to catch the battery. Use the other
hand to rotate the bike in the stand. The battery will
slide out of the downtube.
