2024 Marlin+
16
Front mudguard
The front mudguard is sold separately.
29" wheel
5
7
2
27.5" wheel
5
3
7
4
1
8
8
5
5 Nm
6
5.5 Nm
3
5 Nm
M5 x 12 M6 x 10 M5 x 8
8
M5 x 10
4 Nm
6
1
Front mudguard and strut, 27.5” – 601256
2
Front mudguard and strut, 29” – 601257
3
Screw, M5 x 12 mm, stainless steel – W584855
4
Washer, nylon – 5319894
5
Bolt, M6 x 10 mm, stainless steel
(a longer bolt may be required if using a
light mounting bracket)
601267
6
Bolt, M5 x 8 mm, stainless steel
7
Washer, M5 x 1 mm, stainless steel
8
Bolts, M5 x 10 mm, stainless steel – W549305
*Mudguard parts for the 29" wheel are only compatible with the originally equipped SR SUNTOUR or RockShox fork.
