2024 Marlin+
2
Safety
WARNING
Tighten hardware properly
Always tighten hardware to the specied torque.
Over-tightening hardware could deform or break the
hardware or components. Under-tightening hardware
could cause hardware or components to become loose.
Either situation could damage the bicycle and result in
injury to the rider.
WARNING
Re-apply threadlocker
All reused-fasteners with a pre-applied threadlocker
must be cleaned with isopropyl alcohol and have new
threadlocker applied before re-assembly. If a threadlock-
er is not applied, the fasteners may loosen, which could
damage the bicycle and result in injury to the rider.
Scope
This manual contains parts diagrams, specications (such
as grease and torque values), instructions and helpful tips.
It does not contain instructions for all components (such
as brake callipers). Refer to the original manufacturer for
more information.
Legend
Apply grease
Do not apply grease
Apply threadlocker
Nm
Torque
Zip tie
Additional resources
• Bosch Purion remote quick start guide: trekbikes.com/manuals
• Bosch E-bike Owner’s Manual: trekbikes.com/manuals
• Trek’s YouTube channel: youtube.com/trekbikes
