TREND CRT/MK3 - Edge Moulding and Feed Direction

-20-
CRT/MK3
Edge Moulding
and Grooving
Cutter Rotation
Feed Direction
Feed Direction
Q Always work with constant,
medium rate. Feeding too slow
will results in burn marks and
excessive heat build up of the
cutter.
Q Good results will be obtained
by removing small amounts of
material in several passes.
Q Always feed work in the opposite
direction to the direction of
rotation of the router cutter.
✓
✗
Q Isolate from power source.
Q Fit cutter.
Q Set back fence position.
Q Set top and side pressures.
Q Fit guard.
Q Check all knobs are tight.
Q Plug into power supply.
Q Switch on.
Q Feed right to left.
Q Switch off.
