ITEMS ENCLOSED & DESCRIPTION OF PARTS
1 x
1
/2” (12.7mm) Dovetail template
4 x Template bracket screws
countersunk socket head
1 x Hex key -
1
/8” (3.2mm) A/F
2 x Template bracket complete with
integral nuts
No.1 Edge guides
For
1
/2” (12.7mm) lapped dovetail
template
No.2 Edge guides
For
1
/2” (12.7mm) rebated dovetail &
comb jointing template
2 x Template spring pin stops
2 x Edge guide pan head screws
2 x Edge guide screw washer
1 x Template guide bush 15.7mm
diameter
2 x Countersunk machine screw M5
x 10mm for guide bush
1 x Spanner
7
/16” (11.1mm) A/F for
adjusting template lock nut
1 x Manual
1 x Guarantee Card
-2-
GUARANTEE
1 x Jig body
1 x Front clamping bar
(short) with abrasive
strip
1 x Top clamping bar (long)
with abrasive strip
4 x Nylon spacer
4 x Clamp knob female
4 x Clamp bar set bolt
UNC
1
/4” - 20 x 1
3
/4
(long)
6 x Set bolt half nut
UNC
1
/4” - 20
2 x Template set bolt
UNC
1
/4” - 20 x 1
1
/2
(short)
4 x Spring
2 x Template lock nut
UNC
1
/4” - 20
2 x Knurled brass thumb
screw
1 x Dovetail cutter
12.7mm dia x 104°
4 x Self tapping screw
No.10 x
1
