DJ300
1. Clamp knob female
2. Nylon spacer
3. Clamping bar - short
4. Clamping bar - long
5. Spring
6. Template spring pin stop
7.
1
/2” (12.7mm) dovetail template
8. Template bracket screws
9. Template bracket
10. Dovetail edge guide
11. Edge guide pan head screws
ASSEMBLY
Using the drawing below as a guide to assemble
the jig.
12. Edge guide washer
13. Clamp bar set bolt UNC
1
/4” - 20 x 1
3
/4” (long)
14. Knurled brass thumb screw
15. Edge guide fastening slot
16. Jig body
17. Lock nut UNC
1
/4” - 20
18. Embossed slot for bar set bolt (front slots
hidden from view on diagram above)
19. Template set bolt UNC
1
/4” - 20 x 1
1
/2” (short)
20. Half nut UNC1/4” - 20
21. Embossed slot for template set bolt
-4-
4
16
18
13
20
19
18
20
351421 18 1715 2 1
10
12
11
1
2
5
8
7
9
6
13
19
20
13
18
21
20
13
